ABB System Pro M Compact S200 MCB, 1P, 80A Curve B, 440V AC, 60V DC, 6 kA Breaking Capacity

View all MCBs

Subtotal (1 box of 1 unit)*

£55.21

(exc. VAT)

£66.25

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 18 unit(s) shipping from 27 October 2025
  • Plus 5 unit(s) shipping from 27 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es)
Per Box
1 +£55.21

*price indicative

RS Stock No.:
231-9668
Mfr. Part No.:
2CDS251001R0805 S201-B80 6kA
Brand:
ABB
Find similar products by selecting one or more attributes.
Select all

Brand

ABB

Number of Poles

1

Current Rating

80A

Tripping Characteristics

Type B

Rated AC Voltage

440V

Rated DC Voltage

60V

Breaking Capacity at Maximum Voltage Rating

6 kA

Range

System Pro M Compact

Series

S200

Circuit Breaker Type

MCB

Width

17.5mm

Length

85mm

Mounting Style

DIN Rail Mount

Depth

69mm

Model Number

S201-B80

Terminal Contact Type

Screw Clamp

Reset Actuator Type

Toggle Switch

COO (Country of Origin):
DE

ABB S200 Series MCB, 1 Pole, 80A Current Rating - 2CDS251001R0805 S201-B80 6kA


This miniature circuit breaker is designed for efficient and safe electrical applications. Its compact design allows for straightforward installation on DIN rail systems while providing robust protection against overcurrents. With a Type B tripping characteristic, it demonstrates reliability across various automated and electrical environments.

Features & Benefits


• Simple installation on DIN rail systems
• Operates effectively within a range of -25°C to +55°C
• 6kA short-circuit rating enhances safety
• Clear ON/OFF indication for user convenience
• Energy-limiting capabilities for effective protection
• Compatible with flexible and rigid conductor connections

Applications


• Safeguarding electrical circuits in commercial installations
• Suitable for residential panels requiring circuit protection
• Utilised in industrial automation systems for dependable performance
• Protecting sensitive electrical equipment from surges

What is the maximum voltage this device can handle?


It can manage operational voltages up to 440V AC.

How does it perform in adverse environmental conditions?


It operates efficiently between -25°C and +55°C for reliable use.

What type of connection is recommended for this circuit breaker?


It is compatible with flexible and rigid conductors ranging from 2.5mm² to 50mm².

Can it be easily mounted in tight spaces?


Yes, its compact design allows for mounting in confined areas without issues.

Is there a specific installation requirement for this device?


It must be installed on standard DIN rails for optimal performance.
