ABB System Pro M Compact S200 MCB, 1P, 80A Curve C, 440V AC, 60V DC, 6 kA Breaking Capacity
- RS Stock No.:
- 231-9667
- Mfr. Part No.:
- 2CDS251001R0804 S201-C80 6kA
- Brand:
- ABB
Subtotal (1 box of 1 unit)*
£55.16
(exc. VAT)
£66.19
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 10 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box |
---|---|
1 + | £55.16 |
*price indicative
- RS Stock No.:
- 231-9667
- Mfr. Part No.:
- 2CDS251001R0804 S201-C80 6kA
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ABB | |
Number of Poles | 1 | |
Current Rating | 80A | |
Tripping Characteristics | Type C | |
Rated AC Voltage | 440V | |
Rated DC Voltage | 60V | |
Breaking Capacity at Maximum Voltage Rating | 6 kA | |
Range | System Pro M Compact | |
Series | S200 | |
Circuit Breaker Type | MCB | |
Length | 85mm | |
Width | 17.5mm | |
Mounting Style | DIN Rail Mount | |
Depth | 69mm | |
Model Number | S201-C80 | |
Terminal Contact Type | Screw Clamp | |
Reset Actuator Type | Toggle Switch | |
Select all | ||
---|---|---|
Brand ABB | ||
Number of Poles 1 | ||
Current Rating 80A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 440V | ||
Rated DC Voltage 60V | ||
Breaking Capacity at Maximum Voltage Rating 6 kA | ||
Range System Pro M Compact | ||
Series S200 | ||
Circuit Breaker Type MCB | ||
Length 85mm | ||
Width 17.5mm | ||
Mounting Style DIN Rail Mount | ||
Depth 69mm | ||
Model Number S201-C80 | ||
Terminal Contact Type Screw Clamp | ||
Reset Actuator Type Toggle Switch | ||
- COO (Country of Origin):
- DE
ABB S200 Series MCB, 1 Pole, 80A Current Rating - 2CDS251001R0804 S201-C80 6kA
This miniature circuit breaker provides efficient protection for electrical circuits across various applications. The 1P Type C configuration facilitates quick disconnection during overloads or short circuits, thus protecting equipment and improving operational safety. With a current rating of 80A and a 6kA short-circuit capacity, this device is essential for ensuring dependable electrical systems in industrial environments.
Features & Benefits
• Type C tripping characteristics for effective performance
• DIN Rail Mount allows for straightforward installation into existing systems
• 80A current rating accommodates a wide range of loads
• 6kA short-circuit protection capability
• Part of the System Pro M Compact range for efficient space utilisation
• Compliant with IEC/EN standards for safety and performance
• DIN Rail Mount allows for straightforward installation into existing systems
• 80A current rating accommodates a wide range of loads
• 6kA short-circuit protection capability
• Part of the System Pro M Compact range for efficient space utilisation
• Compliant with IEC/EN standards for safety and performance
Applications
• Suitable for industrial automation environments
• Effective for electrical distribution in commercial buildings
• Compatible with machinery needing circuit protection at 80A
• Commonly installed in control cabinets for critical equipment
• Effective for electrical distribution in commercial buildings
• Compatible with machinery needing circuit protection at 80A
• Commonly installed in control cabinets for critical equipment
How do I install it properly?
Ensure secure mounting on a DIN Rail, aligning with IEC 60715 specifications.
What maintenance is required for this device?
Regularly check connections and physical condition to maintain proper functioning.
Can it handle varying loads effectively?
Yes, it is designed to accommodate different loads while providing protective tripping.
What type of wires can be used with it?
Flexible and rigid conductors between 2.5mm² and 50mm² are compatible.
Is it suitable for residential applications?
While primarily intended for industrial use, it can be adapted for residential circuit protection if necessary.
