ABB System Pro M Compact S200 MCB, 4P, 25A Curve K
- RS Stock No.:
- 225-6006
- Mfr. Part No.:
- 2CDS254001R0517 S204 K 25A - 10 KA
- Brand:
- ABB
Subtotal (1 unit)*
£155.53
(exc. VAT)
£186.64
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £155.53 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 225-6006
- Mfr. Part No.:
- 2CDS254001R0517 S204 K 25A - 10 KA
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Number of Poles | 4 | |
| Current Rating | 25A | |
| Tripping Characteristics | Type K | |
| Range | System Pro M Compact | |
| Series | S200 | |
| Mounting Style | DIN Rail Mount | |
| Model Number | S204-K25A | |
| Better World Product | Yes | |
| Better World Claim | Designed for disassembly | |
Select all | ||
|---|---|---|
Brand ABB | ||
Number of Poles 4 | ||
Current Rating 25A | ||
Tripping Characteristics Type K | ||
Range System Pro M Compact | ||
Series S200 | ||
Mounting Style DIN Rail Mount | ||
Model Number S204-K25A | ||
Better World Product Yes | ||
Better World Claim Designed for disassembly | ||
The ABB S200 series miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electro mechanic tripping mechanism for short circuit protection. It has clear contact position indication with red colour for ON and green colour for OFF.
Degree of protection IP20
High performance at an increased rated voltage for marine and industrial applications
Unique, patented twin terminal with captive screws and an increased opening for cables up to maximum 35 mm2
High performance at an increased rated voltage for marine and industrial applications
Unique, patented twin terminal with captive screws and an increased opening for cables up to maximum 35 mm2
