ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 4A, Type K, 400V AC, 10 kA Breaking Capacity

RS Stock No.:: 225-6004
Mfr. Part No.:: 2CDS254001R0337 S204 K 4A - 10 KA
Brand:: ABB

ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 4A, Type K, 400V AC, 10 kA Breaking Capacity

View all MCBs

Subtotal (1 unit)*

£112.89

(exc. VAT)

£135.47

(inc. VAT)

FREE delivery for orders over £60.00

Stocked by manufacturer

Ready to ship from 15 June 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£112.89

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:: 225-6004
Mfr. Part No.:: 2CDS254001R0337 S204 K 4A - 10 KA
Brand:: ABB

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Number of Poles	4
	Product Type	Miniature Circuit Breaker
	Current Rating	4A
	Tripping Characteristics	Type K
	Rated AC Voltage	400V
	Breaking Capacity	10kA
	Mount Type	DIN Rail
	Range	System Pro M Compact
	Series	S200
	Terminal Type	Screw
	IP Rating	IP20, IP40
	Depth	69mm
	Standards/Approvals	IEC/EN 60898-1, IEC/EN 60947-2
	Height	88mm
	Width	70mm
	Better World Claim	Designed for Disassembly
	Better World Product	Yes
	Reset Actuator Type	Toggle Switch
	Tripping Mechanism	Thermal

	Select all
	Brand ABB
	Number of Poles 4
	Product Type Miniature Circuit Breaker
	Current Rating 4A
	Tripping Characteristics Type K
	Rated AC Voltage 400V
	Breaking Capacity 10kA
	Mount Type DIN Rail
	Range System Pro M Compact
	Series S200
	Terminal Type Screw
	IP Rating IP20, IP40
	Depth 69mm
	Standards/Approvals IEC/EN 60898-1, IEC/EN 60947-2
	Height 88mm
	Width 70mm
	Better World Claim Designed for Disassembly
	Better World Product Yes
	Reset Actuator Type Toggle Switch
	Tripping Mechanism Thermal

ABB S200 Series MCB, 4A Current Rating , 4 Poles - 2CDS254001R0337 S204 K 4A - 10 KA

This 4 Pole MCB is designed for use in various commercial and industrial applications, providing exceptional overload protection and thermal tripping functionality. With a Compact structure measuring 70mm in width, 69mm in length, and 69mm in depth, it is suitable for DIN rail mounting, offering easy installation and maintenance.

Features & Benefits

• Designed for disassembly to facilitate recycling efforts
• Thermal tripping mechanism provides reliable circuit interruption
• High breaking capacity of 20kA enhances system safety
• Toggle switch reset actuator ensures user friendly operation
• Screw Terminal contact type offers secure connections
• Type K characteristics suit specific load applications

Applications

• Used for protecting electrical circuits in commercial settings
• Suitable for industrial machinery requiring reliable circuit protection
• Ideal for demanding overload protection
• Utilised in environments with high fault currents

What kind of protection does this device provide against electrical overloads?

The thermal tripping mechanism ensures that the circuit is interrupted if the current exceeds the rated capacity, providing effective overload protection to prevent equipment damage.

How can I mount this device for optimal performance?

It is designed for easy installation on DIN rails, allowing quick and secure mounting within a distribution board or control panel to facilitate straightforward integration.

What is the significance of the high breaking capacity?

A breaking capacity of 20kA ensures the circuit breaker can safely interrupt fault currents, protecting downstream equipment from damage during overcurrent situations.

In what scenarios would a Type K characteristic be advantageous?

Type K characteristics are beneficial in applications where inductive loads are prevalent, as they provide a delayed tripping response to accommodate the initial inrush currents without unnecessary interruptions.
