ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 25 A, Type Z, 440 V ac AC, 110 V DC, 20 kA Breaking

View all MCBs

Subtotal (1 unit)*

£200.67

(exc. VAT)

£240.80

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 19 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£200.67

*price indicative

RS Stock No.:
237-3328
Mfr. Part No.:
2CDS254001R0518 S204 Z 25A - 10 KA
Brand:
ABB
Find similar products by selecting one or more attributes.
Select all

Brand

ABB

Number of Poles

4

Product Type

Miniature Circuit Breaker

Current Rating

25 A

Tripping Characteristics

Type Z

Rated AC Voltage

440 V ac

Rated DC Voltage

110 V

Breaking Capacity

20kA

Range

System Pro M Compact

Series

S200

IP Rating

IP20, IP40

Height

88mm

Standards/Approvals

IEC/EN 60947-2, UL 1077

Depth

69mm

Width

70 mm

Tripping Mechanism

Anaerobic Adhesive, Electromechanic

COO (Country of Origin):
DE
The ABB system pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electro mechanic tripping mechanism for short circuit protection. They are available in different characteristics Z configurations 4P breaking capacities (up to 6 kA at 230/400 V AC) and rated currents 25A.

All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077

Degree of Protection IP20

Ambient Air Temperature : Operation -25 to +55 °C, Storage -40 to +70 °C
