Eaton xPole PXL, S200 MCB, 3P, 8A Curve C, 400V AC, 48V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 489-923
- Mfr. Part No.:
- 236421 PXL-C8/3
- Brand:
- Eaton
Available to back order for despatch 27/06/2024, delivery within 2 working days
Not available for guaranteed pre 9am/10am delivery
Added
Price Each
£81.59
(exc. VAT)
£97.91
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £81.59 |
| 10 - 14 | £76.70 |
| 15 + | £73.42 |
- RS Stock No.:
- 489-923
- Mfr. Part No.:
- 236421 PXL-C8/3
- Brand:
- Eaton
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- AT
Product Details
PXL series, C characteristic, 3-pole
Circuit breaker with high selectivity as a pre-fuse with low passband energy
Bus bar compatible
With double terminal, lift / jaw top and bottom
Free selection of rail arrangement top and bottom
Finger-proof / back-of-hand-proof
Quick-fit action with 3 locking positions for top-hat rail IEC / EN 60715
Bus bar compatible
With double terminal, lift / jaw top and bottom
Free selection of rail arrangement top and bottom
Finger-proof / back-of-hand-proof
Quick-fit action with 3 locking positions for top-hat rail IEC / EN 60715
Standards
IEC / EN 60898
Note
Eaton formerly known as Moeller
Specifications
Attribute | Value |
|---|---|
| Number of Poles | 3P |
| Current Rating | 8A |
| Tripping Characteristics | Type C |
| Rated AC Voltage | 400V |
| Rated DC Voltage | 48V |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Range | xPole |
| Series | PXL, S200 |
| Circuit Breaker Type | MCB |
| Length | 52.5mm |
| Width | 80mm |
| Mounting Style | DIN Rail Mount |
| Depth | 60mm |
