Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 0.5 A, Type D, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 248-630
- Mfr. Part No.:
- 102257 FAZ-D0,5/3-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£233.72
(exc. VAT)
£280.46
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £233.72 |
*price indicative
- RS Stock No.:
- 248-630
- Mfr. Part No.:
- 102257 FAZ-D0,5/3-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 0.5 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 15kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Depth | 105mm | |
| Standards/Approvals | CSA C. . 5 CSA (File . 0445) CE CSAC. . 509 IECEN 60947 UL 489 EN45545 IEC 617, RoHS IEC 60947 CSA (Class . 1401) UL (File . E519) UL 489 | |
| Height | 75.5mm | |
| Width | 14 mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 0.5 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 15kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Depth 105mm | ||
Standards/Approvals CSA C. . 5 CSA (File . 0445) CE CSAC. . 509 IECEN 60947 UL 489 EN45545 IEC 617, RoHS IEC 60947 CSA (Class . 1401) UL (File . E519) UL 489 | ||
Height 75.5mm | ||
Width 14 mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series designed specifically for North American use, ensuring optimal performance in feeder and branch circuits. This innovative switchgear boasts a compact, three pole construction and is UL listed, making it compliant with the stringent standards required for safe electrical systems. With its robust design and easy integration into existing systems, this product represents the pinnacle of modern electrical engineering, delivering peace of mind for users demanding high quality circuit protection.
Meets rigorous safety certifications including UL and CSA standards
Designed with a compact form factor optimising space in electrical panels
Utilises advanced thermal and electromagnetic protection mechanisms
Offers a high tripping characteristic for dependable operation
Equipped with dual purpose terminals for increased installation flexibility
Provides IP20 protection safeguarding against dust and accidental contact
Capable of enduring up to 20000 electrical operations ensuring long lasting reliability
