Eaton xEffect FAZ Miniature Circuit Breaker, 2-Pole, 0.5 A, Type D, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 248-612
- Mfr. Part No.:
- 102177 FAZ-D0,5/2-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£166.67
(exc. VAT)
£200.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £166.67 |
*price indicative
- RS Stock No.:
- 248-612
- Mfr. Part No.:
- 102177 FAZ-D0,5/2-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 2 | |
| Current Rating | 0.5 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Width | 35.4 mm | |
| Standards/Approvals | UL 489, UL File No. E235139, UL Category Control Number DIVQ, IEC 60947-2, IEC 61373, CSA C22.2 No. 5, CSA, IEC EN 60947-2, UL, CE, CSA-C22.2 No. 5-09, CSA Class No. 1432-01, CSA File No. 204453, EN45545-2 | |
| Depth | 70.5mm | |
| Height | 75.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 2 | ||
Current Rating 0.5 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Width 35.4 mm | ||
Standards/Approvals UL 489, UL File No. E235139, UL Category Control Number DIVQ, IEC 60947-2, IEC 61373, CSA C22.2 No. 5, CSA, IEC EN 60947-2, UL, CE, CSA-C22.2 No. 5-09, CSA Class No. 1432-01, CSA File No. 204453, EN45545-2 | ||
Depth 70.5mm | ||
Height 75.5mm | ||
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series provides unparalleled protection and reliability, ensuring the safety of your electrical installations. With its robust tripping characteristic and a rated current of 0.5 A, it is engineered to handle feeder and branch circuits effectively. Its compact dimensions allow for versatile installation options, granting you the ease of integration into various switchgear applications. Its innovative design facilitates easier maintenance while providing exceptional performance in diverse operating conditions.
Offers advanced protection with high short circuit breaking capacity
Widely compatible with various conductor sizes for versatile applications
Enhanced degree of protection safeguards against environmental factors
Robust mechanical and electrical lifespan ensures long term reliability
User friendly installation method simplifies the assembly process
Safety features protect against finger and hand touch hazards
