Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 0.5 A, Type D, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 240-482
- Mfr. Part No.:
- 102297 FAZ-D0,5/3-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£336.15
(exc. VAT)
£403.38
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £336.15 |
*price indicative
- RS Stock No.:
- 240-482
- Mfr. Part No.:
- 102297 FAZ-D0,5/3-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 0.5 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Height | 75.5mm | |
| Depth | 70.5mm | |
| Standards/Approvals | CE, CSA C. . 5, CSAC. . 509, CSA (Class . 1401), EN45545, IEC 60947, IEC 617, IECEN 60947, RoHS, rth America (UL,CSA ), UL, UL 489, UL (File . E519) | |
| Width | 53.1 mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 0.5 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Height 75.5mm | ||
Depth 70.5mm | ||
Standards/Approvals CE, CSA C. . 5, CSAC. . 509, CSA (Class . 1401), EN45545, IEC 60947, IEC 617, IECEN 60947, RoHS, rth America (UL,CSA ), UL, UL 489, UL (File . E519) | ||
Width 53.1 mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series designed for demanding industrial and advanced commercial environments, this device excels in protecting feeder and branch circuits from overloads and short circuits. With a robust three pole configuration and innovative tripping characteristics, it ensures optimal performance while maintaining compliance with stringent safety standards. The product boasts a compact design that simplifies installation, making it ideal for installations requiring a dependable, space efficient solution.
Offers a high rated switching capacity for enhanced reliability
Designed for ease of installation on top hat rails
Constructed to operate effectively in a wide range of ambient temperatures
Utilises twin purpose terminals for versatile wiring connections
Provides immunity to mechanical impacts for robust performance
Conforms to global standards ensuring installation safety
Equipped with a high short circuit breaking capacity to protect electrical networks
