Eaton xEffect FAZ Miniature Circuit Breaker, 2-Pole, 2A, Type B, 415V ac AC, 60 V dc DC, 10 kA Breaking Capacity
- RS Stock No.:
- 246-115
- Mfr. Part No.:
- 132695 FAZ-B2/2-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£109.65
(exc. VAT)
£131.58
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 16 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £109.65 |
*price indicative
- RS Stock No.:
- 246-115
- Mfr. Part No.:
- 132695 FAZ-B2/2-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 2 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 2A | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 415V ac | |
| Rated DC Voltage | 60V dc | |
| Breaking Capacity | 10kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP40, IP20 | |
| Width | 35.4mm | |
| Height | 75.5mm | |
| Standards/Approvals | UL (File No. E235139), UL (Category Control Number DIVQ), UL 489, North America (UL,CSA ), IEC/EN 60947-2, IEC 61373, IEC 60947-2, EN45545-2, CSA (File No. 204453), CSA (Class No. 1432-01), CSA-C22.2 No. 5-09, CSA C22.2 No. 5, CE marking | |
| Depth | 70.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 2 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 2A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 415V ac | ||
Rated DC Voltage 60V dc | ||
Breaking Capacity 10kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP40, IP20 | ||
Width 35.4mm | ||
Height 75.5mm | ||
Standards/Approvals UL (File No. E235139), UL (Category Control Number DIVQ), UL 489, North America (UL,CSA ), IEC/EN 60947-2, IEC 61373, IEC 60947-2, EN45545-2, CSA (File No. 204453), CSA (Class No. 1432-01), CSA-C22.2 No. 5-09, CSA C22.2 No. 5, CE marking | ||
Depth 70.5mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker is designed for optimal performance in North American applications. Built to meet stringent safety standards, this two-pole device ensures reliable switching and protection for your electrical systems. Its innovative design caters to a variety of electrical conditions, allowing it to function effectively across both AC and DC circuits. The compact size ensures easy installation while offering superior thermal stability and corrosion resistance, making it an ideal choice for installing in diverse environments.
Top-hat rail mounting ensures straightforward installation and adaptability
Finger and hand touch-safe terminals contribute to user safety during setup
Current limiting capabilities enhance overall circuit protection performance
Wide ambient operating temperature range allows use in different environments
