Eaton xEffect FAZ Miniature Circuit Breaker, 2-Pole, 4 A, Type C, 415 V ac AC, 60 V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 240-569
- Mfr. Part No.:
- 102162 FAZ-C4/2-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£153.64
(exc. VAT)
£184.37
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £153.64 |
*price indicative
- RS Stock No.:
- 240-569
- Mfr. Part No.:
- 102162 FAZ-C4/2-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 2 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 4 A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 10kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Width | 35.4 mm | |
| Depth | 105mm | |
| Standards/Approvals | CE, CSA C. . 5, CSAC. . 509, CSA (Class . 1401), EN45545, IEC 60947, IEC 617, IECEN 60947, RoHS, rth America (UL,CSA ), UL, UL 489, UL (File . E519) | |
| Height | 75.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 2 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 4 A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 10kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Width 35.4 mm | ||
Depth 105mm | ||
Standards/Approvals CE, CSA C. . 5, CSAC. . 509, CSA (Class . 1401), EN45545, IEC 60947, IEC 617, IECEN 60947, RoHS, rth America (UL,CSA ), UL, UL 489, UL (File . E519) | ||
Height 75.5mm | ||
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is engineered specifically for North American applications. Designed with a two pole configuration, it boasts a tripping characteristic of C and a rated current of 4 A, ensuring reliable protection in branch circuits and feeder circuits. Its UL listing and CSA certification highlight its compliance with stringent safety standards, ideal for both commercial and residential settings.
Compact dimensions facilitate easy enclosure integration
Offers twin purpose terminals for flexible wiring options
Suitable for various configurations with an adjustable mounting position
Designed for quick and straightforward installation on a top hat rail
Meets multiple international electrical standards for reliability
Supports an extensive operating temperature range enhancing versatility
