Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 32 A, Type D, 415 V AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 240-487
- Mfr. Part No.:
- 102314 FAZ-D32/3-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£238.39
(exc. VAT)
£286.07
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £238.39 |
*price indicative
- RS Stock No.:
- 240-487
- Mfr. Part No.:
- 102314 FAZ-D32/3-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 3 | |
| Current Rating | 32 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 15kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP40, IP20 | |
| Depth | 105mm | |
| Height | 75.5mm | |
| Standards/Approvals | rth America (UL,CSA ), RoHS, IECEN 60947, IEC 617, IEC 60947, EN45545, CSA Std. C. .5, CSA (File . 0445), CSA (Class . 1401), CSAC. . 509, CSA C. . 5, CE, UL (File . E519), UL 489, UL 1077, UL | |
| Width | 53.1 mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 3 | ||
Current Rating 32 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 15kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP40, IP20 | ||
Depth 105mm | ||
Height 75.5mm | ||
Standards/Approvals rth America (UL,CSA ), RoHS, IECEN 60947, IEC 617, IEC 60947, EN45545, CSA Std. C. .5, CSA (File . 0445), CSA (Class . 1401), CSAC. . 509, CSA C. . 5, CE, UL (File . E519), UL 489, UL 1077, UL | ||
Width 53.1 mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is engineered to provide reliable protection for both feeder and branch circuits in industrial and advanced commercial applications. With its robust design, it is specifically tailored for North American standards, ensuring compliance with various certifications including UL and CSA. The three pole configuration is equipped with a tripping characteristic of D, making it exceptionally effective for applications needing a higher short circuit breaking capacity.
Compact design allows for easy installation in standard panels
Rated insulation voltage supports versatile operational settings
Equipped with twin purpose terminals for flexible conductor connections
Designed to be finger and hand touch safe for enhanced user safety
Meets high performance standards for operational lifespan and reliability
