Eaton xEffect FAZ Miniature Circuit Breaker, 2-Pole, 32 A, Type D, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 248-624
- Mfr. Part No.:
- 102234 FAZ-D32/2-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£169.48
(exc. VAT)
£203.38
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £169.48 |
*price indicative
- RS Stock No.:
- 248-624
- Mfr. Part No.:
- 102234 FAZ-D32/2-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 2 | |
| Current Rating | 32 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Width | 35.4 mm | |
| Height | 75.5mm | |
| Depth | 70.5mm | |
| Standards/Approvals | IEC/EN 60947-2, CE marking, CSA (File No. 204453), IEC 60947-2, UL 489, UL (File No. E235139) | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 2 | ||
Current Rating 32 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Width 35.4 mm | ||
Height 75.5mm | ||
Depth 70.5mm | ||
Standards/Approvals IEC/EN 60947-2, CE marking, CSA (File No. 204453), IEC 60947-2, UL 489, UL (File No. E235139) | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is designed to provide exceptional protection in industrial and advanced commercial applications. Its robust construction and smart engineering make it an ideal choice for branch circuits and feeder circuits where operational efficiency and safety are paramount.
Accords high insulation voltage ratings enhancing safety during operational use
Equipped with easy to use twin purpose terminals for versatile connectivity
Designed for simple installation on standard top hat rail systems
Supports a substantial operational lifetime with a lifespan of up to 20000 cycles
Facilitates an operational temperature range suitable for various environmental conditions
Withstands external influences offering IP40 protection when installed correctly
Boasts an impressive impulse withstand voltage for added resilience
