Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 6A, Type D, 415V ac AC, 60 V dc DC, 15 kA Breaking Capacity
- RS Stock No.:
- 241-228
- Mfr. Part No.:
- 102304 FAZ-D6/3-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£233.72
(exc. VAT)
£280.46
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 30 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £233.72 |
*price indicative
- RS Stock No.:
- 241-228
- Mfr. Part No.:
- 102304 FAZ-D6/3-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 6A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415V ac | |
| Rated DC Voltage | 60V dc | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Width | 53.1mm | |
| Standards/Approvals | UL (Category Control Number DIVQ), UL (File No. E235139), CSA C22.2 No. 5, CSA-C22.2 No. 5-09, CSA (Class No. 1432-01), CSA (File No. 204453), EN45545-2, IEC 60947-2, IEC 61373, IEC/EN 60947-2, UL 489 | |
| Height | 75.5mm | |
| Depth | 70.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 6A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415V ac | ||
Rated DC Voltage 60V dc | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Width 53.1mm | ||
Standards/Approvals UL (Category Control Number DIVQ), UL (File No. E235139), CSA C22.2 No. 5, CSA-C22.2 No. 5-09, CSA (Class No. 1432-01), CSA (File No. 204453), EN45545-2, IEC 60947-2, IEC 61373, IEC/EN 60947-2, UL 489 | ||
Height 75.5mm | ||
Depth 70.5mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series offers advanced protection for branch circuits, ensuring reliability and safety in both industrial and commercial applications. Designed for ease of installation on a top hat rail, this circuit breaker features a robust current rating and a three pole configuration, catering specifically to the demands of North American electrical standards. With its D tripping characteristic, it guarantees optimal protection against overload and short circuit conditions, making it an essential component for modern electrical systems.
Includes twin purpose terminals for versatile connections
Finger and hand touch safety feature for enhanced user protection
Compliant with RoHS for environmental sustainability
IP20 protection rating enables secure operation in protected environments
Easy integration into existing electrical systems with a compact design
