Renesas Electronics ISL81387IAZ-T Line Transceiver, CMOS/TTL, 20-Pin QFN
- RS Stock No.:
- 196-8659P
- Mfr. Part No.:
- ISL81387IAZ-T
- Brand:
- Renesas Electronics
Bulk discount available
Subtotal 10 units (supplied on a continuous strip)*
£43.15
(exc. VAT)
£51.78
(inc. VAT)
Add 12 units to get free delivery
In Stock
- Plus 682 unit(s) shipping from 16 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 10 - 18 | £4.315 |
| 20 - 48 | £4.13 |
| 50 - 98 | £3.955 |
| 100 + | £3.82 |
*price indicative
- RS Stock No.:
- 196-8659P
- Mfr. Part No.:
- ISL81387IAZ-T
- Brand:
- Renesas Electronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Renesas Electronics | |
| Product Type | Line Transceiver | |
| Logic Family | CMOS | |
| Logic Function | TTL, CMOS | |
| IC Type | Transceiver | |
| Input Type | Differential | |
| Output Type | CMOS/TTL | |
| Mount Type | Surface | |
| Package Type | QFN | |
| Pin Count | 20 | |
| Minimum Supply Voltage | 5V | |
| Maximum Supply Voltage | 7V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Propagation Delay Time @ CL | 2μs | |
| Maximum Operating Temperature | 85°C | |
| Length | 7.33mm | |
| Height | 2.65mm | |
| Width | 7.9 mm | |
| Series | ISL81387 | |
| Standards/Approvals | No | |
| Automotive Standard | No | |
| Supply Current | 7mA | |
| Select all | ||
|---|---|---|
Brand Renesas Electronics | ||
Product Type Line Transceiver | ||
Logic Family CMOS | ||
Logic Function TTL, CMOS | ||
IC Type Transceiver | ||
Input Type Differential | ||
Output Type CMOS/TTL | ||
Mount Type Surface | ||
Package Type QFN | ||
Pin Count 20 | ||
Minimum Supply Voltage 5V | ||
Maximum Supply Voltage 7V | ||
Minimum Operating Temperature -40°C | ||
Maximum Propagation Delay Time @ CL 2μs | ||
Maximum Operating Temperature 85°C | ||
Length 7.33mm | ||
Height 2.65mm | ||
Width 7.9 mm | ||
Series ISL81387 | ||
Standards/Approvals No | ||
Automotive Standard No | ||
Supply Current 7mA | ||
The Renesas ISL81387IAZ-T is BiCMOS Interface IC that are user configured as either a single RS-422, RS-485 differential transceiver, or as a dual (2 Tx, 2 Rx) RS-232 transceiver. Both RS-232, RS-485 modes feature loopback and shutdown functions. The loopback mode internally connects the Tx outputs to the corresponding Rx input, which facilitates the implementation of board level self test functions.
Full fail-safe (open/short) Rx in RS-485, RS-422 mode
Fast RS-232 data rate of up to 650kbps
Low current shutdown mode 35μA
