SICK WEO16P Series Light Curtain Receiver, 1 Beam(s)
- RS Stock No.:
- 285-9091
- Mfr. Part No.:
- WEO16P-2416R500A00ZLLZZZZZZZZ1
- Brand:
- SICK
Subtotal (1 unit)*
£193.93
(exc. VAT)
£232.72
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3 unit(s) ready to ship from another location
- Plus 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £193.93 |
*price indicative
- RS Stock No.:
- 285-9091
- Mfr. Part No.:
- WEO16P-2416R500A00ZLLZZZZZZZZ1
- Brand:
- SICK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SICK | |
| Series | WEO16P | |
| Component Type | Receiver | |
| Safety Type | 2 | |
| SIL IEC 61508 | SIL 1 | |
| PL EN ISO 13849-1 | PL c | |
| Number of Beams | 1 | |
| Maximum Scanning Distance | 20m | |
| Maximum Response Time | 0.5 ms | |
| Length | 55.4mm | |
| Height | 42mm | |
| Supply Voltage | 24 V dc | |
| Terminal Type | M26 Connector | |
| Width | 20mm | |
| Dimensions | 20 x 42 x 55.4 mm | |
Select all | ||
|---|---|---|
Brand SICK | ||
Series WEO16P | ||
Component Type Receiver | ||
Safety Type 2 | ||
SIL IEC 61508 SIL 1 | ||
PL EN ISO 13849-1 PL c | ||
Number of Beams 1 | ||
Maximum Scanning Distance 20m | ||
Maximum Response Time 0.5 ms | ||
Length 55.4mm | ||
Height 42mm | ||
Supply Voltage 24 V dc | ||
Terminal Type M26 Connector | ||
Width 20mm | ||
Dimensions 20 x 42 x 55.4 mm | ||
- COO (Country of Origin):
- DE
Overview
The L25 and L26 product families from SICK represent a new generation of single-beam photoelectric safety switch for type 2 applications, which, in combination with an external test device, facilitate operations and make processes safer and more efficient
Thanks to the ultra rugged VISTAL® housing and predictive maintenance, the L25 and L26 are extremely reliable and prevent unscheduled machine downtime.
At a glance
BluePilot: optical alignment aid
Smart Sensor: efficient communication with IO-Link
Ultra rugged VISTAL® housing
Enclosure rating: IP66, IP67 and IP69K
Typical scanning range of up to 20 m
Type of light: IR light and visible red light
Standardized connect
Smart Sensor: efficient communication with IO-Link
Ultra rugged VISTAL® housing
Enclosure rating: IP66, IP67 and IP69K
Typical scanning range of up to 20 m
Type of light: IR light and visible red light
Standardized connect
Your Benefit
Quick and precise alignment of the sender and the receiver thanks to the PinPoint LED in combination with BluePilot
Increased productivity: Smart Sensor diagnostic functions always available via IO-Link
Cost efficiency: IP66, IP67 and IP69K guarantee a lo
Increased productivity: Smart Sensor diagnostic functions always available via IO-Link
Cost efficiency: IP66, IP67 and IP69K guarantee a lo
Applications
Machine tools: access protection and area safeguarding
Consumer goods: access protection for cutting machines
Storage and conveyor (intralogistics): access protection for mobile storage systems (high-bay warehouse)
Consumer goods: access protection for cutting machines
Storage and conveyor (intralogistics): access protection for mobile storage systems (high-bay warehouse)
Note
Product details cover the whole product family. For details on the specifications for this individual product, please refer to the datasheet.
