2.1 V, 2.2 V Green & Yellow LED 5mm Through Hole, Kingbright L-59GYW

  • RS Stock No. 228-5792
  • Mfr. Part No. L-59GYW
  • Brand Kingbright
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

Kingbright Through Hole Multi-Colour LED Series

This family of LEDs, from Kingbright, are multi-colour devices. They come in bi-colour and full colour options in various through hole package types. There are also water clear and diffused lens types.
The multi-colour LEDs offer long life solid-state reliability with low power consumptions. Their uniform light output makes them ideal for general purpose applications.

Features of the Multi-Colour LEDs:
Variety of package sizes: 3 mm, 5 mm, 8 mm and 10 mm
Packages shapes: Round, Cylindrical and Rectangular
Range of colour options: Bi-colour and full colour

//media.rs-online.com/t_line/L228568-01.gif
//media.rs-online.com/t_line/LE228568-01.gif

Visible Light LEDs, Kingbright

Specifications
Attribute Value
LED Colours Green, Yellow
Package Type 5mm (T-1 3/4)
Mounting Type Through Hole
Number of LEDs 2
Forward Voltage 2.1 V, 2.2 V
Luminous Intensity 50 mcd
Number of Pins 3
Viewing Angle 60 °
Lens Shape Round
Dominant Wavelength 568 / 588 nm
Dimensions 5mm
Lens Colour Clear
934 In stock - FREE next working day delivery available
Price Each
£ 2.00
(exc. VAT)
£ 2.40
(inc. VAT)
Units
Per unit
1 - 39
£2.00
40 - 99
£0.23
100 - 249
£0.19
250 - 499
£0.16
500 +
£0.15
