HENSEL KF Series Grey Polycarbonate Terminal Box, IP66, 5 Terminals, DNV GL, IEC 60670-22, 92 mm, 210 mm 155 mm
- RS Stock No.:
- 276-5401
- Mfr. Part No.:
- KF 1616 B
- Brand:
- HENSEL
Subtotal (1 unit)*
£56.95
(exc. VAT)
£68.34
(inc. VAT)
Add 1 unit to get free delivery
Temporarily out of stock
- Shipping from 27 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £56.95 |
*price indicative
- RS Stock No.:
- 276-5401
- Mfr. Part No.:
- KF 1616 B
- Brand:
- HENSEL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HENSEL | |
| Product Type | Terminal Box | |
| Length | 92mm | |
| Width | 210 mm | |
| Material | Polycarbonate | |
| Height | 155mm | |
| IP Rating | IP66 | |
| Number of Terminals | 5 | |
| Colour | Grey | |
| Hazardous Area Certification | DNV GL, IEC 60670-22 | |
| Number of Ways | 10 | |
| Cable Entry | 2 x M32 | |
| Current Rating | 102 A | |
| Standards/Approvals | DNV GL - Certificate No: TAE00000EE, IEC 60670-22 | |
| Series | KF | |
| Select all | ||
|---|---|---|
Brand HENSEL | ||
Product Type Terminal Box | ||
Length 92mm | ||
Width 210 mm | ||
Material Polycarbonate | ||
Height 155mm | ||
IP Rating IP66 | ||
Number of Terminals 5 | ||
Colour Grey | ||
Hazardous Area Certification DNV GL, IEC 60670-22 | ||
Number of Ways 10 | ||
Cable Entry 2 x M32 | ||
Current Rating 102 A | ||
Standards/Approvals DNV GL - Certificate No: TAE00000EE, IEC 60670-22 | ||
Series KF | ||
- COO (Country of Origin):
- DE
6-16 mm², Cu 3∼
Terminal with 2 clamping units per pole
5-pole per pole 6 x 6 mm² r / f, 4 x 10 mm² r / f, 4 x 16 mm² s / f, 4 x 25 mm² s / f, 2 x 35 mm² s / f
With two cable entries M 32 from the rear side
Cable entries via knockouts, order ASS glands separately (see cable entry systems LES)
"Weatherproof" resistant to weather influences (UV due to solar radiation, protected against rainwater,
Temperature resistant, impact resistant, etc.)
Saltwater-proof
"Offshore applications"
Lid fasteners sealable without accessories
External brackets for wall fixing included
Colour: black, RAL 9011
