Schneider Electric 3-Pole Surface Isolator Switch -, IP40, 22A, 22 kW
- RS Stock No.:
- 280-8200
- Mfr. Part No.:
- 28902
- Brand:
- Schneider Electric
Bulk discount available
Subtotal (1 unit)*
£98.83
(exc. VAT)
£118.60
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 18 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £98.83 |
| 5 - 9 | £95.79 |
| 10 + | £91.69 |
*price indicative
- RS Stock No.:
- 280-8200
- Mfr. Part No.:
- 28902
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Product Type | Isolator Switch | |
| Number of Poles | 3 | |
| Mount Type | Surface | |
| IP Rating | IP40 | |
| Electrical Phase | 3 | |
| Handle Colour | Black | |
| Terminal Type | Wire | |
| Switching Current | 22A | |
| Auxiliary Contacts Available | No | |
| Series | ComPacT INS | |
| Switching AC Voltage | 240V ac | |
| Switching Power | 22kW | |
| Switching DC Voltage | 250V dc | |
| Padlock Compatibility | No | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 70°C | |
| Hazardous Area Certification | NO | |
| Standards/Approvals | EU, RoHS | |
| Depth | 62.5mm | |
| Width | 81mm | |
| Length | 90mm | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Product Type Isolator Switch | ||
Number of Poles 3 | ||
Mount Type Surface | ||
IP Rating IP40 | ||
Electrical Phase 3 | ||
Handle Colour Black | ||
Terminal Type Wire | ||
Switching Current 22A | ||
Auxiliary Contacts Available No | ||
Series ComPacT INS | ||
Switching AC Voltage 240V ac | ||
Switching Power 22kW | ||
Switching DC Voltage 250V dc | ||
Padlock Compatibility No | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 70°C | ||
Hazardous Area Certification NO | ||
Standards/Approvals EU, RoHS | ||
Depth 62.5mm | ||
Width 81mm | ||
Length 90mm | ||
- COO (Country of Origin):
- IT
Interpact INS40/160 series switches
Perform isolation and switching with positive contact indication of the electrical distribution circuits.
They are used as inlet switches on the modular distribution board, on the PLC box and cabinet or on the local box for local control of motor circuits, machine tools, etc.
Locking by 3 padlocks in "OFF" position.
Locking in "ON" position possible.
Front or side rotating control as standard.
Extended rotating control maintains isolation ability.
Standards
IEC 947-1 and 947-3, EN 60947-1 and EN 947-3, NFC 79130 and CNOMO
