Socomec 4P Pole Isolator Switch - 160A Maximum Current, 75kW Power Rating, IP20
- RS Stock No.:
- 122-0483
- Mfr. Part No.:
- 22004016
- Brand:
- Socomec
Subtotal (1 unit)*
£160.09
(exc. VAT)
£192.11
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
- Plus 1 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £160.09 |
*price indicative
- RS Stock No.:
- 122-0483
- Mfr. Part No.:
- 22004016
- Brand:
- Socomec
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Socomec | |
Number of Poles | 4P | |
Maximum Current | 160A | |
IP Rating | IP20 | |
Power Rating | 75kW | |
Voltage Rating | 415 V ac, 690V ac | |
Electrical Phase | 3 | |
Series | SIRCO M | |
Range | SIRCO | |
Length | 109mm | |
Width | 124.6mm | |
Depth | 69.9mm | |
Minimum Operating Temperature | -25°C | |
Terminal Type | Screw | |
Maximum Operating Temperature | +70°C | |
Select all | ||
---|---|---|
Brand Socomec | ||
Number of Poles 4P | ||
Maximum Current 160A | ||
IP Rating IP20 | ||
Power Rating 75kW | ||
Voltage Rating 415 V ac, 690V ac | ||
Electrical Phase 3 | ||
Series SIRCO M | ||
Range SIRCO | ||
Length 109mm | ||
Width 124.6mm | ||
Depth 69.9mm | ||
Minimum Operating Temperature -25°C | ||
Terminal Type Screw | ||
Maximum Operating Temperature +70°C | ||
- COO (Country of Origin):
- TN
Non-Fusible Disconnect Switches SIRCO MV
SIRCO MV are manually operated and modular multipolar load break switches, and with visible breaking.
Available in 3 or 4 poles and from 100 to 160A, they make and break under load conditions and provide safety isolation for any low voltage circuit, particularly for machine control circuits.
• Comply with international standard IEC 60947-3
• Visible double breaking based on a sliding contact system,
• Positive break indication.
