- RS Stock No.:
- 153-2919
- Mfr. Part No.:
- 74HC2G04GW,125
- Brand:
- Nexperia
24550 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 50)
£0.269
(exc. VAT)
£0.323
(inc. VAT)
Units | Per unit | Per Pack* |
50 - 200 | £0.269 | £13.45 |
250 - 450 | £0.128 | £6.40 |
500 - 1200 | £0.121 | £6.05 |
1250 - 2450 | £0.09 | £4.50 |
2500 + | £0.085 | £4.25 |
*price indicative |
- RS Stock No.:
- 153-2919
- Mfr. Part No.:
- 74HC2G04GW,125
- Brand:
- Nexperia
Technical Reference
Legislation and Compliance
Product Details
Mixed 5 V and 3.3 V applications
Improved current drive and voltage level of signals
Improved signal integrity for complex layouts
Wide supply voltage range
Low propagation delay
TTL input options
3-state output options
Overvoltage tolerant options
Registered options
LCD TV
Cell phones
Industrial monitoring
STB
Improved current drive and voltage level of signals
Improved signal integrity for complex layouts
Wide supply voltage range
Low propagation delay
TTL input options
3-state output options
Overvoltage tolerant options
Registered options
LCD TV
Cell phones
Industrial monitoring
STB
Dual inverter, The 74HC2G04, 74HCT2G04 is a high-speed Si-gate CMOS device. The 74HC2G04, 74HCT2G04 provides two inverting buffers.
Specifications
Attribute | Value |
---|---|
Logic Function | Buffer, Inverter |
Input Type | CMOS, Schmitt Trigger |
Output Type | CMOS |
Number of Elements per Chip | 2 |
Schmitt Trigger Input | Yes |
Maximum Propagation Delay Time @ Maximum CL | 110 ns @ 50 pF |
Maximum High Level Output Current | -5.2mA |
Maximum Low Level Output Current | 5.2mA |
Mounting Type | Surface Mount |
Package Type | SC-88 |
Pin Count | 6 |
Logic Family | HC |
Dimensions | 2.2 x 1.35 x 1mm |
Maximum Operating Supply Voltage | 6 V |
Height | 1mm |
Width | 1.35mm |
Minimum Operating Temperature | -40 °C |
Minimum Operating Supply Voltage | 2 V |
Maximum Operating Temperature | +125 °C |
Propagation Delay Test Condition | 50pF |
Length | 2.2mm |
- RS Stock No.:
- 153-2919
- Mfr. Part No.:
- 74HC2G04GW,125
- Brand:
- Nexperia
