Bulgin Circular Connector, 5 Contacts, Panel Mount, Socket, Female, IP68, Buccaneer 900 Series
- RS Stock No.:
- 239-9247
- Distrelec Article No.:
- 144-66-231
- Mfr. Part No.:
- PX0931/05/S
- Brand:
- Bulgin
Bulk discount available
Subtotal (1 unit)*
£37.43
(exc. VAT)
£44.92
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1,192 unit(s) ready to ship
- Plus 8 unit(s) ready to ship from another location
- Plus 50 unit(s) shipping from 31 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £37.43 |
| 10 - 49 | £34.96 |
| 50 - 99 | £33.95 |
| 100 + | £32.98 |
*price indicative
- RS Stock No.:
- 239-9247
- Distrelec Article No.:
- 144-66-231
- Mfr. Part No.:
- PX0931/05/S
- Brand:
- Bulgin
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Number of Contacts | 5 | |
| Mounting Type | Panel Mount | |
| Connector Size | Standard | |
| Plug/Socket | Socket | |
| Contact Gender | Female | |
| Termination Method | Screw | |
| IP Rating | IP68 | |
| Current Rating | 25A | |
| Series | Buccaneer 900 | |
| Body Orientation | Straight | |
| Voltage Rating | 600 V | |
| Mating Type | Threaded | |
| Housing Material | Polyamide | |
| Contact Plating | Nickel | |
| Contact Material | Brass | |
| Series Number | PX0931 | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
| Outer Diameter | 50mm | |
Select all | ||
|---|---|---|
Brand Bulgin | ||
Number of Contacts 5 | ||
Mounting Type Panel Mount | ||
Connector Size Standard | ||
Plug/Socket Socket | ||
Contact Gender Female | ||
Termination Method Screw | ||
IP Rating IP68 | ||
Current Rating 25A | ||
Series Buccaneer 900 | ||
Body Orientation Straight | ||
Voltage Rating 600 V | ||
Mating Type Threaded | ||
Housing Material Polyamide | ||
Contact Plating Nickel | ||
Contact Material Brass | ||
Series Number PX0931 | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -40°C | ||
Outer Diameter 50mm | ||
- COO (Country of Origin):
- TN
Bulgin Buccaneer 900 Series Circular Connector, 5 Contacts, IP68 - PX0931/05/S
This circular connector features a panel mount design. It is equipped with five contacts and constructed for high-performance connectivity within challenging environments. Designed for durability, it meets an IP68 rating, ensuring protection against dust and moisture intrusion.
Features & Benefits
• Water and dustproof performance when properly connected
• Fast-acting locking mechanism allows operation while wearing gloves
• Suitable for panel thicknesses between 3mm and 7mm
• Offers screw termination for secure connections
• Capable of handling high current loads up to 25A
• Fast-acting locking mechanism allows operation while wearing gloves
• Suitable for panel thicknesses between 3mm and 7mm
• Offers screw termination for secure connections
• Capable of handling high current loads up to 25A
Applications
• Used with industrial machinery for reliable power distribution
• Applicable in automation systems requiring robust connectors
• Ideal for outdoor equipment exposed to harsh weather conditions
• Utilised in electrical installations needing a secure connection
• Applicable in automation systems requiring robust connectors
• Ideal for outdoor equipment exposed to harsh weather conditions
• Utilised in electrical installations needing a secure connection
What kind of materials are used in the construction of this connector?
The body is made of polyamide plastic, offering exceptional durability, while the contacts are constructed from brass with nickel plating to enhance conductivity and resistance to corrosion.
Can it be used in environments with variable temperatures?
Yes, it operates effectively within a temperature range of -40°C to +85°C, making it suitable for various industrial environments.
What are the specific wire gauge requirements for connections?
The connector accommodates wire sizes ranging from 2.5mm² to 4mm², complying with AWG standards of 10AWG to 14AWG, enabling flexible wiring options.
How does the IP68 rating affect its usability?
The IP68 rating ensures that the connector is highly resistant to dust ingress and can withstand immersion in water, providing reliability in outdoor conditions or wet locations.
Is there a sealing cap available for the unmated connector?
Yes, a sealing cap (PX0970/PX0992) can be purchased separately to maintain the IP rating when the connector is not in use, ensuring its integrity over time.
