Bulgin Circular Connector, 6 Contacts, In-line, Plug, Male, IP68, Standard Buccaneer Series
- RS Stock No.:
- 489-576
- Mfr. Part No.:
- PX0740/P/07
- Brand:
- Bulgin
Bulk discount available
Subtotal (1 unit)*
£22.59
(exc. VAT)
£27.11
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 75 unit(s) ready to ship
- Plus 40 unit(s) ready to ship from another location
- Plus 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £22.59 |
| 10 - 49 | £20.78 |
| 50 - 99 | £19.68 |
| 100 + | £18.05 |
*price indicative
- RS Stock No.:
- 489-576
- Mfr. Part No.:
- PX0740/P/07
- Brand:
- Bulgin
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Number of Contacts | 6 | |
| Mounting Type | In-line | |
| Connector Size | Standard | |
| Plug/Socket | Plug | |
| Contact Gender | Male | |
| Termination Method | Screw | |
| IP Rating | IP68 | |
| Current Rating | 5.0A | |
| Series | Standard Buccaneer | |
| Body Orientation | Straight | |
| Voltage Rating | 250.0 V | |
| Mating Type | Threaded | |
| Shell Size | 38 | |
| Housing Material | Polymer | |
| Strain Relief | No | |
| Contact Plating | Nickel | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | -20°C | |
| Outer Diameter | 38.1mm | |
| Contact Material | Brass | |
Select all | ||
|---|---|---|
Brand Bulgin | ||
Number of Contacts 6 | ||
Mounting Type In-line | ||
Connector Size Standard | ||
Plug/Socket Plug | ||
Contact Gender Male | ||
Termination Method Screw | ||
IP Rating IP68 | ||
Current Rating 5.0A | ||
Series Standard Buccaneer | ||
Body Orientation Straight | ||
Voltage Rating 250.0 V | ||
Mating Type Threaded | ||
Shell Size 38 | ||
Housing Material Polymer | ||
Strain Relief No | ||
Contact Plating Nickel | ||
Maximum Operating Temperature +70°C | ||
Minimum Operating Temperature -20°C | ||
Outer Diameter 38.1mm | ||
Contact Material Brass | ||
- COO (Country of Origin):
- TN
Bulgin Standard Buccaneer Series Circular Connector, 5A Current Rating, IP68 - PX0740/P/07
This circular connector is designed for performance in harsh environments. Built to meet the needs of various applications, it provides a secure connection while resisting water and dust ingress. Its strong construction and sealing capabilities make it a vital component for industries needing dependable performance in adverse weather conditions.
Features & Benefits
• Screw termination for a dependable electrical connection
• Brass contacts with nickel plating for increased durability and conductivity
• Designed for industrial, automotive, and marine applications
• Brass contacts with nickel plating for increased durability and conductivity
• Designed for industrial, automotive, and marine applications
Applications
• Connections in outdoor electrical systems
• Ideal for industrial automation and machinery
• Suitable for marine electronic installations
• Used in automotive electrical
• Ideal for industrial automation and machinery
• Suitable for marine electronic installations
• Used in automotive electrical
What temperature range can it operate in?
It operates effectively between -20°C and +70°C, suitable for extreme conditions.
How do I ensure a waterproof seal during installation?
Ensure the sealing components are correctly positioned and tightened to achieve an effective seal against moisture.
What types of cables can be accommodated?
The connector accepts cables with diameters from 3.5mm to 9mm, depending on the terminal used.
Approvals
CSA; UL; VDE
