Infineon IGW100N60H3FKSA1 IGBT, 140 A 600 V, 3-Pin PG-TO247-3, Through Hole
- RS Stock No.:
- 273-7430
- Mfr. Part No.:
- IGW100N60H3FKSA1
- Brand:
- Infineon
Available to back order for despatch 23/09/2024
Price Each (In a Tube of 30)
£5.362
(exc. VAT)
£6.434
(inc. VAT)
Units | Per unit | Per Tube* |
|---|---|---|
| 30 - 90 | £5.362 | £160.86 |
| 120 + | £4.915 | £147.45 |
*price indicative
- RS Stock No.:
- 273-7430
- Mfr. Part No.:
- IGW100N60H3FKSA1
- Brand:
- Infineon
Technical Reference
Legislation and Compliance
Product Details
The Infineon IGBT is a high speed IGBT in Trench and Field stop technology. This IGBT has 175 degree Celsius maximum junction temperature and qualified according to JEDEC for target applications. This IGBT is recommended for uninterruptible power supplies, welding converters and converters with high switching frequency applications.
Low EMI
Low VCEsat
RoHS compliant
Pb free lead plating
Very low turn off energy
Halogen free mould compound
Low VCEsat
RoHS compliant
Pb free lead plating
Very low turn off energy
Halogen free mould compound
Specifications
Attribute | Value |
|---|---|
| Maximum Continuous Collector Current | 140 A |
| Maximum Collector Emitter Voltage | 600 V |
| Maximum Gate Emitter Voltage | +/-20V |
| Number of Transistors | 1 |
| Maximum Power Dissipation | 714 W |
| Package Type | PG-TO247-3 |
| Mounting Type | Through Hole |
| Pin Count | 3 |
