STMicroelectronics STGSB200M65DF2AG, NPN-Channel Single IGBT, 200 A 650 V, 9-Pin ECOPACK, Surface Mount
- RS Stock No.:
- 273-5094
- Mfr. Part No.:
- STGSB200M65DF2AG
- Brand:
- STMicroelectronics
Available to back order for despatch 23/10/2024
Added
Price Each
£18.40
(exc. VAT)
£22.08
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £18.40 |
| 10 - 49 | £17.48 |
| 50 - 99 | £16.60 |
| 100 - 149 | £15.77 |
| 150 + | £14.98 |
- RS Stock No.:
- 273-5094
- Mfr. Part No.:
- STGSB200M65DF2AG
- Brand:
- STMicroelectronics
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The STMicroelectronics automotive-grade trench gate field-stop low-loss M series IGBT in an ACEPACK SMIT package. This device is an IGBT developed using an advanced proprietary trench gate field stop structure. The device is part of the M series IGBTs, which represent an optimal balance between inverter system performance and efficiency where the low-loss and the short-circuit functionality is essential.
Tight parameter distribution
Low thermal resistance
Dice on direct bond copper (DBC) substrate
Low thermal resistance
Dice on direct bond copper (DBC) substrate
Specifications
Attribute | Value |
|---|---|
| Maximum Continuous Collector Current | 200 A |
| Maximum Collector Emitter Voltage | 650 V |
| Maximum Gate Emitter Voltage | ±20V |
| Maximum Power Dissipation | 714 W |
| Number of Transistors | 2 |
| Package Type | ECOPACK |
| Configuration | Single |
| Mounting Type | Surface Mount |
| Channel Type | NPN |
| Pin Count | 9 |
- RS Stock No.:
- 273-5094
- Mfr. Part No.:
- STGSB200M65DF2AG
- Brand:
- STMicroelectronics
