Infineon IGBT, 80 A PG-TO-247, Surface
- RS Stock No.:
- 258-1019
- Mfr. Part No.:
- IKW75N60H3FKSA1
- Brand:
- Infineon
Bulk discount available
Subtotal (1 tube of 30 units)*
£114.96
(exc. VAT)
£137.94
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Tube* |
|---|---|---|
| 30 - 30 | £3.832 | £114.96 |
| 60 - 120 | £3.64 | £109.20 |
| 150 + | £3.487 | £104.61 |
*price indicative
- RS Stock No.:
- 258-1019
- Mfr. Part No.:
- IKW75N60H3FKSA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Maximum Continuous Collector Current Ic | 80A | |
| Product Type | IGBT | |
| Maximum Power Dissipation Pd | 428W | |
| Package Type | PG-TO-247 | |
| Mount Type | Surface | |
| Maximum Collector Emitter Saturation Voltage VceSAT | 2.3V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 175°C | |
| Series | IKW75 | |
| Height | 5.21mm | |
| Length | 16.13mm | |
| Width | 21.13 mm | |
| Standards/Approvals | RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Maximum Continuous Collector Current Ic 80A | ||
Product Type IGBT | ||
Maximum Power Dissipation Pd 428W | ||
Package Type PG-TO-247 | ||
Mount Type Surface | ||
Maximum Collector Emitter Saturation Voltage VceSAT 2.3V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 175°C | ||
Series IKW75 | ||
Height 5.21mm | ||
Length 16.13mm | ||
Width 21.13 mm | ||
Standards/Approvals RoHS | ||
Automotive Standard No | ||
The Infineon high speed 600 V, 75 A hard-switching TRENCHSTOP IGBT3 co-packed with free-wheeling diode in a TO-247 package provides the best compromise between switching and conduction losses. The key feature of this family is a MOSFET-like turn-off switching behaviour, leading to low turn off losses.
Low switching and conduction losses
Very good EMI behaviour
Can be used with a small gate resistor for reduced delay time and voltage overshoot
