Mitsubishi Electric PM100CG1B120#300G, Type N-Channel IGBT Module, 100 A 1200 V Module, Surface

View all IGBTs
Bulk discount available

Subtotal (1 box of 10 units)*

£3,232.25

(exc. VAT)

£3,878.70

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 02 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
10 - 20£323.225£3,232.25
30 - 90£293.813£2,938.13
100 +£269.247£2,692.47

*price indicative

RS Stock No.:
207-4975
Mfr. Part No.:
PM100CG1B120#300G
Brand:
Mitsubishi Electric
Find similar products by selecting one or more attributes.
Select all

Brand

Mitsubishi Electric

Maximum Continuous Collector Current Ic

100A

Product Type

IGBT Module

Maximum Collector Emitter Voltage Vceo

1200V

Maximum Power Dissipation Pd

595W

Package Type

Module

Mount Type

Surface

Channel Type

Type N

Maximum Collector Emitter Saturation Voltage VceSAT

2.1V

Minimum Operating Temperature

-20°C

Maximum Operating Temperature

150°C

Series

PM100CG1B120

Standards/Approvals

RoHS Directive 2011/65/EU, UL under UL1557

Automotive Standard

No

The Mitsubishi Electric 1200V intelligent module power has high performance and high reliability IGBT with six driver per module. It has 150 A of maximum continuous collector current and in this error output signal is available from each protection upper and lower arm of IPM.

Adopting full-gate CSTBT chip

Outputting an error signal corresponding to the abnormal state
