Lapp ÖLFLEX HEAT Series Black 1.5 mm² Hook Up Wire, 15 AWG, 19/0.25 mm, 100m, Silicone Insulation, 51001
- RS Stock No.:
- 724-4541
- Distrelec Article No.:
- 301-58-407
- Mfr. Part No.:
- 51001
- Brand:
- Lapp
Subtotal (1 reel of 100 metres)*
£99.80
(exc. VAT)
£119.76
(inc. VAT)
FREE delivery for orders over £50.00
- 11 unit(s) ready to ship
- Plus 4 unit(s) ready to ship from another location
- Plus 11 unit(s) shipping from 28 October 2025
Reel(s) | Per Reel | Per Metre* |
---|---|---|
1 + | £99.80 | £0.998 |
*price indicative
- RS Stock No.:
- 724-4541
- Distrelec Article No.:
- 301-58-407
- Mfr. Part No.:
- 51001
- Brand:
- Lapp
Select all | Attribute | Value |
---|---|---|
Brand | Lapp | |
Cross Sectional Area | 1.5 mm² | |
Sheath Colour | Black | |
Cable Shape | Single Core | |
American Wire Gauge | 15 AWG | |
Core Strands | 19/0.25 mm | |
Length | 100m | |
Insulation Material | Silicone | |
Voltage Rating | 300 V | |
Outer Diameter | 2.8mm | |
Minimum Operating Temperature | -50°C | |
CPR Certification | Eca | |
Maximum Operating Temperature | +180°C | |
Conductor Material | Copper | |
Standards Met | EAC | |
Cable Type | High Temperature | |
Fire Behaviour | Flame Retardant | |
Series | ÖLFLEX HEAT | |
Shield Type | Unshielded | |
Size of Strands | 0.25 mm | |
Resistant To | Chemicals, Oils | |
Outer Sheath Material | Silicone Rubber | |
Number of Strands | 1 | |
Select all | ||
---|---|---|
Brand Lapp | ||
Cross Sectional Area 1.5 mm² | ||
Sheath Colour Black | ||
Cable Shape Single Core | ||
American Wire Gauge 15 AWG | ||
Core Strands 19/0.25 mm | ||
Length 100m | ||
Insulation Material Silicone | ||
Voltage Rating 300 V | ||
Outer Diameter 2.8mm | ||
Minimum Operating Temperature -50°C | ||
CPR Certification Eca | ||
Maximum Operating Temperature +180°C | ||
Conductor Material Copper | ||
Standards Met EAC | ||
Cable Type High Temperature | ||
Fire Behaviour Flame Retardant | ||
Series ÖLFLEX HEAT | ||
Shield Type Unshielded | ||
Size of Strands 0.25 mm | ||
Resistant To Chemicals, Oils | ||
Outer Sheath Material Silicone Rubber | ||
Number of Strands 1 | ||
- COO (Country of Origin):
- DE
Olflex Heat 180 SiF
The cable has a flexible fine-wire conductor, and is halogen free, ensuring it is suitable for a wide range of applications. It also has resistance to oils, fats and chemical substances.
Features and Benefits
• Temperature Resistance
• Cold Resistance
• Resistance to some oils and chemical substances
• Halogen-free according to IEC 60754-1
• Corrosiveness of combustion gases according to IEC 60754-2
• Flame-retardant according IEC 60332-1-2
• Operating Temperature -50 °C to +180 °C (Adequate Ventilation Required)
• Minimum bending radius 6 x cable diameter for fixed applications
Applications
The Lapp OLFLEX HEAT 180 SiF cable is highly versatile, but its temperature resistance makes it particularly suited to;
• HVAC Systems
• Thermal and Heating Elements
• Furnace Construction
• Generator and Transformer Manufacturing
• Lighting Technology
Which wire types are a better choice, stranded or solid?
Both stranded and solid wire have the same resistance properties but stranded wire guarantee an extra flexibility, resistance to bending and are generally easier to install than solid cables.
Note
LAPP High Temperature Wire, -50°C to +180°C Operating Temperature Range, Unshielded -ÖLFLEX HEAT Series - 51001
• 500V rating supports demanding connections
• Black sheath colour for easy identification in your setup
• Unshielded type for enhanced flexibility
Applications
• Lighting installations
• Generator manufacturing
How long is this high temperature wire?
