Belden 83009 Series Red 0.81 mm² Hook Up Wire, 18 AWG, 19/0.25 mm, 30.5m, TFE Insulation, 83009 002100
- RS Stock No.:
- 136-6338
- Mfr. Part No.:
- 83009 002100
- Brand:
- Belden
Subtotal (1 reel of 30 metres)*
£84.14
(exc. VAT)
£100.97
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 4 unit(s) shipping from 31 October 2025
- Plus 6 unit(s) shipping from 23 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £84.14 | £2.805 |
*price indicative
- RS Stock No.:
- 136-6338
- Mfr. Part No.:
- 83009 002100
- Brand:
- Belden
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Belden | |
| Cross Sectional Area | 0.81 mm² | |
| Sheath Colour | Red | |
| American Wire Gauge | 18 AWG | |
| Cable Shape | Single Core | |
| Core Strands | 19/0.25 mm | |
| Length | 30.5m | |
| Insulation Material | TFE | |
| Voltage Rating | 600 V ac | |
| Outer Diameter | 1.73mm | |
| Maximum Operating Temperature | +200°C | |
| Minimum Operating Temperature | -70°C | |
| Conductor Material | Copper | |
| Wire Style | UL1371 | |
| Standards Met | MIL-W-16878/4, NEMA HP3 | |
| Fire Behaviour | Flame Retardant | |
| Series | 83009 | |
| Hook Up Wire Type | High Temperature | |
| Insulation Wall Thickness | 0.3mm | |
| Number of Strands | 19 | |
| Size of Strands | 30 AWG | |
Select all | ||
|---|---|---|
Brand Belden | ||
Cross Sectional Area 0.81 mm² | ||
Sheath Colour Red | ||
American Wire Gauge 18 AWG | ||
Cable Shape Single Core | ||
Core Strands 19/0.25 mm | ||
Length 30.5m | ||
Insulation Material TFE | ||
Voltage Rating 600 V ac | ||
Outer Diameter 1.73mm | ||
Maximum Operating Temperature +200°C | ||
Minimum Operating Temperature -70°C | ||
Conductor Material Copper | ||
Wire Style UL1371 | ||
Standards Met MIL-W-16878/4, NEMA HP3 | ||
Fire Behaviour Flame Retardant | ||
Series 83009 | ||
Hook Up Wire Type High Temperature | ||
Insulation Wall Thickness 0.3mm | ||
Number of Strands 19 | ||
Size of Strands 30 AWG | ||
- COO (Country of Origin):
- MX
Belden Hook Up Wire, Silver-Coated Copper Conductor, 600Vrms Voltage Rating - 83009 002100
Looking for a reliable messenger to carry signals to your electronic components? Choose this hook up wire from Belden. Its single copper core offers a low resistance of 5.75Ohm/1000ft, so you get smooth transmission. To ensure it's safe to handle, the cable comes with TFE insulation that keeps you protected against electric shocks. This material also resists impact, so the wire holds its own in rugged industrial environments where bumps and scrapes are likely.
Features & Benefits
• Wire reel length of 30.5m provides enough for numerous jobs
• Silver conductor coating for corrosion resistance to ensure long-lasting performance
• Safe to use in extreme conditions thanks to an operating temperature range between -70°C and +200°C
• Silver conductor coating for corrosion resistance to ensure long-lasting performance
• Safe to use in extreme conditions thanks to an operating temperature range between -70°C and +200°C
Applications
• Consumer electronics
• Medical equipment
• Automotive industry
• Medical equipment
• Automotive industry
Can I reuse this cable?
Yes, as long as you properly desolder or uninstall it from its previous terminal point, you can reuse this cable as many times as you want.
