HARTING Heavy Duty Power Connector Insert, 10A, HAN Brid Series Female, 2 Contacts
- RS Stock No.:
- 175-1389
- Mfr. Part No.:
- 09120032770
- Brand:
- HARTING
Subtotal (1 unit)*
£44.30
(exc. VAT)
£53.16
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £44.30 |
*price indicative
- RS Stock No.:
- 175-1389
- Mfr. Part No.:
- 09120032770
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Current Rating | 10A | |
| Product Type | Heavy Duty Power Connector Insert | |
| Series | HAN Brid | |
| Sub Type | Hybrid RJ45 Module | |
| Connector Gender | Female | |
| For Use With | Heavy Duty Power Connector | |
| Pole Format | 2 | |
| Number of Rows | 1 | |
| Voltage | 24V | |
| Mount Type | PCB | |
| Manufacturer Size Code | 3A | |
| Number of Contacts | 2 | |
| Standards/Approvals | RoHS, CSA-C22.2 No. 182.3 ECBT8.E235076, IEC 61984, UL 1977 ECBT2.E235076 | |
| Contact Material | Polycarbonate | |
| Orientation | Straight | |
| Select all | ||
|---|---|---|
Brand HARTING | ||
Current Rating 10A | ||
Product Type Heavy Duty Power Connector Insert | ||
Series HAN Brid | ||
Sub Type Hybrid RJ45 Module | ||
Connector Gender Female | ||
For Use With Heavy Duty Power Connector | ||
Pole Format 2 | ||
Number of Rows 1 | ||
Voltage 24V | ||
Mount Type PCB | ||
Manufacturer Size Code 3A | ||
Number of Contacts 2 | ||
Standards/Approvals RoHS, CSA-C22.2 No. 182.3 ECBT8.E235076, IEC 61984, UL 1977 ECBT2.E235076 | ||
Contact Material Polycarbonate | ||
Orientation Straight | ||
Suitable for standard RJ 45 Plug and Jack, shielded version
Connection of the device side can be realised either by a printed circuit board as a modular version or as part of the appliance PCB
Assembly with standard tools
Insert for 2 Han-D® male or female contacts offers the combination with electrical bus connector
