Molex 93604 Series Grey RAL 7001 Die Cast Aluminium Enclosure, IP66, IP69 100 mm, 240 mm, 160 mm
- RS Stock No.:
- 250-2167
- Mfr. Part No.:
- 936040115
- Brand:
- Molex
Bulk discount available
Subtotal (1 unit)*
£211.57
(exc. VAT)
£253.88
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 8 unit(s) shipping from 13 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £211.57 |
| 10 - 24 | £204.79 |
| 25 - 49 | £201.42 |
| 50 + | £194.64 |
*price indicative
- RS Stock No.:
- 250-2167
- Mfr. Part No.:
- 936040115
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Product Type | Enclosure | |
| Body Material | Die Cast Aluminium | |
| External Height | 100mm | |
| External Length | 240mm | |
| External Width | 160mm | |
| IP Rating | IP66, IP69 | |
| Lid Colour | Grey | |
| Colour | Grey RAL 7001 | |
| Flanged | No | |
| Hazardous Area Certification | No | |
| Internal Mount Type | Through Hole | |
| Series | 93604 | |
| Weight | 1736g | |
| Standards/Approvals | ANSI/UL 50, ANSI/UL 50 E, CSA C22.2 No.94-1-2, EN 62208, NEMA ICS5, NEMA250, NMX-J235/1-2 | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Product Type Enclosure | ||
Body Material Die Cast Aluminium | ||
External Height 100mm | ||
External Length 240mm | ||
External Width 160mm | ||
IP Rating IP66, IP69 | ||
Lid Colour Grey | ||
Colour Grey RAL 7001 | ||
Flanged No | ||
Hazardous Area Certification No | ||
Internal Mount Type Through Hole | ||
Series 93604 | ||
Weight 1736g | ||
Standards/Approvals ANSI/UL 50, ANSI/UL 50 E, CSA C22.2 No.94-1-2, EN 62208, NEMA ICS5, NEMA250, NMX-J235/1-2 | ||
- COO (Country of Origin):
- CN
The Molex enclosure is comprised of die-cast aluminium alloy with polyester powder finish. Product has internal through hole mounting and is available in grey color.
Operating temperature range -40°C to +125°C
Without external mounting flange
