Renesas Electronics HIP2211FRTZ-T7A MOSFET Gate Driver, 3400 mA 10-Pin 20 V, DFN

View all Gate Drivers

Subtotal (1 reel of 250 units)*

£152.25

(exc. VAT)

£182.75

(inc. VAT)

Add to Basket
Select or type quantity
Last RS stock
  • Final 750 unit(s), ready to ship
Units
Per unit
Per Reel*
250 +£0.609£152.25

*price indicative

RS Stock No.:
201-3369
Mfr. Part No.:
HIP2211FRTZ-T7A
Brand:
Renesas Electronics
Find similar products by selecting one or more attributes.
Select all

Brand

Renesas Electronics

Product Type

MOSFET

Output Current

3400mA

Pin Count

10

Package Type

DFN

Fall Time

365ns

Driver Type

MOSFET

Number of Outputs

2

Rise Time

435ns

Minimum Supply Voltage

18V

Maximum Supply Voltage

20V

Minimum Operating Temperature

-65°C

Maximum Operating Temperature

150°C

Height

0.75mm

Series

HIP2211

Length

3mm

Width

2.6 mm

Standards/Approvals

No

Mount Type

Surface

Automotive Standard

No

The Renesas 100V, 3A source, 4A sink high-frequency half-bridge NMOS FET driver belongs to HIP2211 series. This driver has 10 pin configuration. It features a tri-level PWM input with programmable dead time.

Fast propagation delay and matching with 15ns typical delay and 2ns typical matching

It has Integrated 0.5O typical bootstrap diode

115VDC bootstrap supply maximum voltage supports 100V on the half-bridge
