Festo 1/4 in G FRL Assembly, Manual Drain, 40 μm Filtration Size Integrated Pressure Gauge

RS Stock No.:: 202-2959
Distrelec Article No.:: 303-96-499
Mfr. Part No.:: LFR-1/4-D-MINI-KC
Brand:: Festo

Festo 1/4 in G FRL Assembly, Manual Drain, 40 μm Filtration Size Integrated Pressure Gauge

Subtotal (1 unit)*

£207.76

(exc. VAT)

£249.31

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 25 unit(s) shipping from 27 April 2026
Plus 14 unit(s) shipping from 27 April 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£207.76

*price indicative

MS-Series Products

Discover Festo's innovative MS-Series range of products, designed for optimal performance in automation. Enhance your industrial processes today.

Browse the range

RS Stock No.:: 202-2959
Distrelec Article No.:: 303-96-499
Mfr. Part No.:: LFR-1/4-D-MINI-KC
Brand:: Festo

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Festo
	Product Type	FRL Assembly
	Port Size	1/4 in G
	Integrated Pressure Gauge	Yes
	Maximum Flow Rate	1150L/min
	Drain Type	Manual
	Series	LFR
	Filtration Size	40μm
	Pressure Gauge Port Size	1/4 in G
	Minimum Operating Temperature	-10°C
	Maximum Operating Pressure	16 bar
	Maximum Operating Temperature	60°C
	Standards/Approvals	ISO 8573-1:2010
	Pressure Setting Range	0.5 to 12 bar
	Bowl Material	Polycarbonate
	Pressure Gauge Port Thread Standard	G

	Select all
	Brand Festo
	Product Type FRL Assembly
	Port Size 1/4 in G
	Integrated Pressure Gauge Yes
	Maximum Flow Rate 1150L/min
	Drain Type Manual
	Series LFR
	Filtration Size 40μm
	Pressure Gauge Port Size 1/4 in G
	Minimum Operating Temperature -10°C
	Maximum Operating Pressure 16 bar
	Maximum Operating Temperature 60°C
	Standards/Approvals ISO 8573-1:2010
	Pressure Setting Range 0.5 to 12 bar
	Bowl Material Polycarbonate
	Pressure Gauge Port Thread Standard G

COO (Country of Origin):: HU

Festo FRL Assembly, 1 to 16 Bar Operating Pressure, Vertical +/-5° Mounting - LFR-1/4-D-MINI-KC, Numeric Part Number: 185733

This innovative product offers a wide operating temperature range of -10 to +60°C, it is designed for environments that require robust thermal management, maintaining efficiency in diverse settings.

Features & Benefits

• Integrated pressure gauge enables precise monitoring of air pressure

• Manual drain filter simplifies maintenance and reduces downtime

• Polycarbonate bowl enhances visibility and durability

• Adjustable pressure setting allows for customising performance

• 40μm filtration size ensures effective removal of particulates

• Maximum pressure rating of 16bar supports heavy-duty applications

Applications

• Used with pneumatic tools for consistent air delivery

• Suitable for integration in automation systems

• Ideal for applications requiring precise air pressure control

• Employed in machinery to enhance overall performance

Is this product resistant to corrosion?

Yes, it has a corrosion resistance class of CRC 2.

Will it require regular maintenance?

Yes, the manual drain filter should be maintained for optimal function.

Can it be adjusted to lower pressure settings?

Yes, the pressure setting can be adjusted down to 0.5 bar.
