EPCOS B32355C Polypropylene Film Capacitor, 400V ac, ±5%, 3μF, Wire Leads
- RS Stock No.:
- 185-5366
- Mfr. Part No.:
- B32355C4305J015
- Brand:
- EPCOS
Subtotal (1 box of 198 units)*
£865.26
(exc. VAT)
£1,037.52
(inc. VAT)
Stock information currently inaccessible
Units | Per unit | Per Box* |
|---|---|---|
| 198 + | £4.37 | £865.26 |
*price indicative
- RS Stock No.:
- 185-5366
- Mfr. Part No.:
- B32355C4305J015
- Brand:
- EPCOS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EPCOS | |
| Capacitance | 3µF | |
| Voltage | 400V ac | |
| Mounting Type | Wire Leads | |
| Tolerance | ±5% | |
| Series | B32355C | |
| Suppression Class | S3 | |
| Lead Length | 100mm | |
| Depth | 25mm | |
| Height | 60.5mm | |
| Dimensions | 25 Dia. x 60.5mm | |
| Dielectric | Polypropylene | |
| Terminal Type | Solder | |
| Minimum Operating Temperature | -25°C | |
| Dissipation Factor | 30 x 10-3% | |
| Maximum Operating Temperature | +100°C | |
| Lead Diameter | 2mm | |
Select all | ||
|---|---|---|
Brand EPCOS | ||
Capacitance 3µF | ||
Voltage 400V ac | ||
Mounting Type Wire Leads | ||
Tolerance ±5% | ||
Series B32355C | ||
Suppression Class S3 | ||
Lead Length 100mm | ||
Depth 25mm | ||
Height 60.5mm | ||
Dimensions 25 Dia. x 60.5mm | ||
Dielectric Polypropylene | ||
Terminal Type Solder | ||
Minimum Operating Temperature -25°C | ||
Dissipation Factor 30 x 10-3% | ||
Maximum Operating Temperature +100°C | ||
Lead Diameter 2mm | ||
- COO (Country of Origin):
- IN
Self-healing properties
Low dissipation factor
Highest safety level S3 safety class to IEC60252-1 (ed.2) am1
High insulation resistance
IEC 60335-1 compatible
Higher operating temperature class,100 °C
Terminals:Insulated solid copper wire, 0.5 mm2,105°C
Applications
For general sine wave applications,
Mainly as motor run capacitor
Low dissipation factor
Highest safety level S3 safety class to IEC60252-1 (ed.2) am1
High insulation resistance
IEC 60335-1 compatible
Higher operating temperature class,100 °C
Terminals:Insulated solid copper wire, 0.5 mm2,105°C
Applications
For general sine wave applications,
Mainly as motor run capacitor
