RS PRO, 1.5m Cat6, Green RJ45 to Male RJ45 Male, UTP Unshielded, Terminated LSZH Sheath

RS Stock No.:: 286-3159
Brand:: RS PRO

RS PRO, 1.5m Cat6, Green RJ45 to Male RJ45 Male, UTP Unshielded, Terminated LSZH Sheath

Subtotal (1 unit)*

£3.94

(exc. VAT)

£4.73

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

77 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£3.94

*price indicative

RS Stock No.:: 286-3159
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	LAN Category	Cat6
	Length	1.5m
	Terminated/Unterminated	Terminated
	Shield Type	UTP
	Connector 1	RJ45
	Connector 1 Orientation	Straight
	Connector 1 Number of Contacts	8
	Connector 1 Gender	Male
	Connector 2 Number of Contacts	8
	Connector 2	RJ45
	Connector 2 Gender	Male
	Connector 2 Orientation	Straight
	Shielded/Unshielded	Unshielded
	Outer Sheath Material	LSZH
	Sheath Colour	Green
	Wiring Configuration	Straight Through
	Fire Behaviour	Low Smoke Zero Halogen (LSZH)
	Core Strands	7/0.19
	Capacitance	≤5.6nFnF/100m
	Voltage Rating	300V
	Conductor Strand Type	Stranded
	Cable Shape	Round
	Standards Met	EN 50288, IEC 60332.3C, ISO/IEC 11801, TIA/EIA-563-B.2
	American Wire Gauge	24AWG
	Cross Sectional Area	0.1645mm²
	Outer Diameter	5.9mm
	Number of Strands	8
	Current Rating	2.8A

	Select all
	Brand RS PRO
	LAN Category Cat6
	Length 1.5m
	Terminated/Unterminated Terminated
	Shield Type UTP
	Connector 1 RJ45
	Connector 1 Orientation Straight
	Connector 1 Number of Contacts 8
	Connector 1 Gender Male
	Connector 2 Number of Contacts 8
	Connector 2 RJ45
	Connector 2 Gender Male
	Connector 2 Orientation Straight
	Shielded/Unshielded Unshielded
	Outer Sheath Material LSZH
	Sheath Colour Green
	Wiring Configuration Straight Through
	Fire Behaviour Low Smoke Zero Halogen (LSZH)
	Core Strands 7/0.19
	Capacitance ≤5.6nFnF/100m
	Voltage Rating 300V
	Conductor Strand Type Stranded
	Cable Shape Round
	Standards Met EN 50288, IEC 60332.3C, ISO/IEC 11801, TIA/EIA-563-B.2
	American Wire Gauge 24AWG
	Cross Sectional Area 0.1645mm²
	Outer Diameter 5.9mm
	Number of Strands 8
	Current Rating 2.8A

COO (Country of Origin):: CN

RS PRO Ethernet Cable, Cat6 LSZH

This RS PRO Ethernet Cable is a high-performance Cat6 cable designed for Gigabit Ethernet and other network protocols. It is backward compatible with Cat5/5e and Cat3 standards, offering enhanced specifications for crosstalk and system noise reduction. Ideal for environments requiring low smoke zero halogen (LSZH) materials, this cable ensures safety and reliability.

Features and Benefits

Category 6 Cable: Provides performance up to 250 MHz
UTP (Unshielded Twisted Pair): Reduces interference and maintains signal integrity
LS0H (Low Smoke Zero Halogen): Ensures safety in case of fire
Moulded Snagless Boot: Prevents cable damage during installation
24 AWG Bare Copper Cores: Offers durability and efficient data transmission
3P Verified for Gigabit Ethernet: Guarantees high-speed network performance
Standards Compliance: Meets IEC 60332.3C, TIA/EIA-563-B.2, ISO/IEC 11801, EN 50288
PoE Compatible: Supports Power over Ethernet applications

Applications

Data centres
Office networks
Home networking
Telecommunications
Industrial automation

Additional Information

Sheath Colour: Green
Length: 1.5 m
Connector Type: RJ45 Male to Male
Wiring Configuration: Straight Through
