    TE Connectivity, Economy 800 2.54mm Pitch Vertical 20 Way, Through Hole Stamped Pin Open Frame IC Dip Socket, 3A

    RS Stock No.:
    542-3571
    Mfr. Part No.:
    2-1571552-6
    Brand:
    TE Connectivity
    TE Connectivity
    View all DIL Sockets
    576 In stock - FREE next working day delivery available
    Add to Basket
    Units

    Added

    Price Each (In a Tube of 24)

    £1.923

    (exc. VAT)

    £2.308

    (inc. VAT)

    UnitsPer unitPer Tube*
    24 - 336£1.923£46.152
    360 - 1176£1.154£27.696
    1200 - 2376£1.093£26.232
    2400 - 5976£1.062£25.488
    6000 +£1.035£24.84
    *price indicative
    RS Stock No.:
    542-3571
    Mfr. Part No.:
    2-1571552-6
    Brand:
    TE Connectivity
    COO (Country of Origin):
    CH

    Legislation and Compliance

    COO (Country of Origin):
    CH

    Product Details

    TE Connectivity PCB DIP Sockets with Stamped and Formed Contacts - Economy 800 Series


    Economy 800 series PCB DIP sockets with open ladder style frame and 2.54mm centerline. These PCB DIP IC sockets mount vertically and have stamped and formed gold plated contacts with four fingered mating.


    Precision four-finger inner contact provides concentric funnel entry for easy flat and round lead insertion
    "X" and "Y" Stackable
    Open ladder for cooling, cleaning and inspection
    Low profile
    Accommodates rectangular or round IC leads
    Non-wicking, closed bottom sleeve gives 100% protection against flux and solder contamination
    Recognized under the Component Program of Underwriters Laboratories, Inc. file No. E111362
    Beryllium copper inner contact for maximum mechanical and electrical performance


    Approvals

    UL E111362


    Specifications

    AttributeValue
    Number of Contacts20
    Mounting TypeThrough Hole
    Pin TypeStamped
    Pitch2.54mm
    Row Width7.62mm
    Frame TypeOpen Frame
    Termination MethodSolder
    Contact PlatingGold, Tin
    Current Rating3A
    OrientationVertical
    Length25.4mm
    Width4.57mm
    Depth10.16mm
    Dimensions25.4 x 4.57 x 10.16mm
    SeriesEconomy 800
    Housing MaterialPCT
    Minimum Operating Temperature-55°C
    Maximum Operating Temperature+125°C
    Contact MaterialBeryllium Copper
