Cosel DC-DC Converter, ±12V dc/ 1.25A Output, 9 → 18 V dc Input, 30W, Through Hole, +85°C Max Temp -40°C Min Temp
- RS Stock No.:
- 815-9494
- Mfr. Part No.:
- MGW301212
- Brand:
- Cosel
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 815-9494
- Mfr. Part No.:
- MGW301212
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Cosel | |
Output Voltage | ±12V dc | |
Input Voltage Range | 9 → 18 V dc | |
Power Rating | 30W | |
Input Voltage Nominal | 9 → 18 V dc | |
Output Current | 1.25A | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 2 | |
Isolation Voltage | 1.5kV dc | |
Length | 50.8mm | |
Depth | 9.9mm | |
Load Regulation | 600mV | |
Efficiency | 90% | |
Maximum Temperature | +85°C | |
Minimum Temperature | -40°C | |
Select all | ||
---|---|---|
Brand Cosel | ||
Output Voltage ±12V dc | ||
Input Voltage Range 9 → 18 V dc | ||
Power Rating 30W | ||
Input Voltage Nominal 9 → 18 V dc | ||
Output Current 1.25A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Isolation Voltage 1.5kV dc | ||
Length 50.8mm | ||
Depth 9.9mm | ||
Load Regulation 600mV | ||
Efficiency 90% | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
- COO (Country of Origin):
- JP
MGW Series, 15W Dual Output DC-DC Converters
The MGW series of isolated DC-DC converters from Cosel are constructed with a standard 1" x 1" or 1" x 2" footprint. A shielded diecast housing metal case ensures low EMI. Featuring a field failure rate of less than 0.001%, MGW isolated DC-DC converters are highly reliable. Built in overcurrent protection circuitry allows automatic recovery.
Features and Benefits:
6 sided shield
1500 V dc isolation between input and output
I/O isolation voltage DC1,500 V (1 min)
Built in remote ON/OFF
Output voltage can be adjusted by an external variable resistor
Convection/forced air cooling
Internal fuse protection for safety
Standards
UL-60950-1, cUL, EN60950-1
Approvals
UL, C-UL, TÜV, CE
Cosel Isolated DC-DC Converters
