Cosel MGW DC-DC Converter, ±12V dc/ 65mA Output, 4.5 → 9 V dc Input, 1.56W, PCB Mount, +85°C Max Temp -40°C Min

RS Stock No.:: 171-4745
Mfr. Part No.:: MGW1R50512
Brand:: Cosel

Cosel MGW DC-DC Converter, ±12V dc/ 65mA Output, 4.5 → 9 V dc Input, 1.56W, PCB Mount, +85°C Max Temp -40°C Min

Available to back order for despatch 04/11/2024

Price 1 Tube of 10

£100.07

(exc. VAT)

£120.08

(inc. VAT)

Tube(s)	Per Tube	Per unit*
1 - 4	£100.07	£10.007
5 - 9	£97.07	£9.707
10 - 24	£95.07	£9.507
25 - 49	£93.07	£9.307
50 +	£91.07	£9.107

*price indicative

RS Stock No.:: 171-4745
Mfr. Part No.:: MGW1R50512
Brand:: Cosel

Technical Reference

Datasheet

Legislation and Compliance

COO (Country of Origin):: JP

Product Details

Industry Standard
1"X1" (MGS15) , 1"X2" (MGS30)
High efficiency by synchronized rectification circuit (MGS10/MGS15/MGS30)
6 sided shield (MGS15/MGS30)
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
Built-in overvoltage protection circuits (MGS30)
Built-in remote ON/OFF (MGS6/MGS10/MGS15/MGS30)
Output voltage adjustability by external variable resistor (MGS15/MGS30)
High reliability : not built-in aluminium and tantalum electrolytic capacitor

Industry Standard
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
High reliability : not built-in aluminium and tantalum electrolytic capacitor

Specifications

Attribute	Value
Output Voltage	±12V dc
Input Voltage Range	4.5 → 9 V dc
Power Rating	1.56W
Input Voltage Nominal	5 V dc
Output Current	65mA
Mounting Type	PCB Mount
Isolated	Yes
Number of Outputs	2
Package	SIP 6
Isolation Voltage	1kV dc
Depth	12mm
Width	8.5mm
Length	17mm
Series	MGW
Load Regulation	600mV
Efficiency	83%
Minimum Temperature	-40°C
Maximum Temperature	+85°C
