TRACOPOWER TEN 10WIRH Isolated DC-DC Converter, 5.1V dc/ 2000 mA, 160V dc Input, 36V Input 10 W, PCB, 75 °C Max Temp -40
- RS Stock No.:
- 249-7258
- Distrelec Article No.:
- 302-64-275
- Mfr. Part No.:
- TEN 10-11011WIRH
- Brand:
- TRACOPOWER
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£39.00
(exc. VAT)
£46.80
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 30 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £39.00 |
| 5 - 9 | £37.82 |
| 10 - 24 | £36.66 |
| 25 - 49 | £35.10 |
| 50 + | £33.54 |
*price indicative
- RS Stock No.:
- 249-7258
- Distrelec Article No.:
- 302-64-275
- Mfr. Part No.:
- TEN 10-11011WIRH
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Product Type | Isolated DC-DC Converter | |
| Output Voltage 1 | 5.1V dc | |
| Minimum Input Voltage | 36V | |
| Maximum Input Voltage | 160V dc | |
| Output Current 1 | 2000mA | |
| Mount Type | PCB | |
| Input Ratio | 4:1 | |
| MTBF | 1648000h | |
| Number of Outputs | 1 | |
| Number of Pins | 10 | |
| Isolation Voltage | 3kV dc | |
| Package Type | DIP-24 | |
| Maximum Output Power | 10W | |
| Depth | 10.6mm | |
| Width | 20.3mm | |
| Standards/Approvals | No | |
| Length | 31.8mm | |
| Series | TEN 10WIRH | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 75°C | |
| Efficiency | 87% | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Product Type Isolated DC-DC Converter | ||
Output Voltage 1 5.1V dc | ||
Minimum Input Voltage 36V | ||
Maximum Input Voltage 160V dc | ||
Output Current 1 2000mA | ||
Mount Type PCB | ||
Input Ratio 4:1 | ||
MTBF 1648000h | ||
Number of Outputs 1 | ||
Number of Pins 10 | ||
Isolation Voltage 3kV dc | ||
Package Type DIP-24 | ||
Maximum Output Power 10W | ||
Depth 10.6mm | ||
Width 20.3mm | ||
Standards/Approvals No | ||
Length 31.8mm | ||
Series TEN 10WIRH | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 75°C | ||
Efficiency 87% | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
TRACOPOWER TEN 10WIRH Series Isolated DC-DC Converter, 5.1V DC Output Voltage, 10W Power Rating - TEN 10-11011WIRH
This isolated DC-DC converter offers dependable power conversion for various electronic circuits. With an input voltage range of 36 to 160V DC and a nominal output voltage of 5.1V DC, it suits multiple applications. Its solid construction provides consistent performance under challenging conditions, making it suitable for scenarios that require high dependability.
Features & Benefits
• Fully encapsulated DIP-24 package for improved protection
• 3000V isolation voltage enhances safety in critical situations
• 87% conversion efficiency to reduce energy loss
• Wide input voltage range accommodates different operating conditions
• Operates effectively from -40 to +75°C without derating
• Remote on/off functionality offers flexible control options
Applications
• Suitable for railway systems compliant with EN 50155
• Ideal for industrial automation requiring stable power
• Designed for high voltage settings necessitating reinforced isolation
• Useful in electronics requiring PCB mounting
What protection features does it include?
The design features undervoltage lockout, short-circuit protection, and overvoltage protection, ensuring safe operation and minimising damage during fault conditions.
Is it suitable for applications with high temperatures?
Yes, it operates effectively at temperatures up to +75°C, maintaining consistent performance in demanding environments without derating, according to the specifications.
What is the footprint for PCB mounting?
It has a DIP-24 footprint, compatible with various PCB designs while retaining a compact size.
Can this converter handle surge conditions?
The converter is built to endure surge voltages up to 200V DC for brief periods, enhancing its durability in fluctuating electrical environments.
