TRACOPOWER THR 3WI Isolated DC-DC Converter, 12V dc/ 125 mA, 36V dc Input, 9V Input 10 W, Through Hole, 92 °C Max Temp

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£22.53

(exc. VAT)

£27.04

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 10 unit(s) shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 4£22.53
5 - 9£21.86
10 - 24£21.18
25 - 49£20.28
50 +£19.38

*price indicative

RS Stock No.:
249-5513
Distrelec Article No.:
302-64-397
Mfr. Part No.:
THR 3-2422WI
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Output Voltage 1

12V dc

Product Type

Isolated DC-DC Converter

Minimum Input Voltage

9V

Maximum Input Voltage

36V dc

Output Current 1

125mA

Output Current 2

-125mA

Output Voltage 2

12V dc

Mount Type

Through Hole

Input Ratio

4:1

Number of Outputs

2

MTBF

3360000h

Number of Pins

7

Isolation Voltage

3kV dc

Package Type

DIP-24

Maximum Output Power

10W

Depth

12mm

Length

31.8mm

Standards/Approvals

No

Series

THR 3WI

Maximum Operating Temperature

92°C

Minimum Operating Temperature

-40°C

Efficiency

83%

RoHS Status: Exempt

COO (Country of Origin):
TW
The TRACOPOWER the THR 3WI is 3 Watt DC/DC converters series with reinforced isolation (3000 VAC). These regulated DC/DC converters come in either a DIP-24 package and also feature increased resistance against shock and vibration according to EN 61373. The THR 3WI offers an internal input filter to comply with EN 55032 class A

Reinforced I/O-isolation 3000 VAC

Shock and vibration resistance according to EN 61373

Wide 4:1 input voltage range: 9-36, 18-75, 40-160 VDC

Operating temperature range -40 to +92°C

Internal EN 55032 class A filter

High efficiency up to 85%

Protection against overload, overvoltage and short circuit

3-year product warranty
