TDK-Lambda CHVM DC/DC Converter, 1500V dc/, 12V Input 1 mA, 12V Input, 1.5 W, Through Hole, Through Hole, 50 °C Max Temp
- RS Stock No.:
- 222-7209
- Mfr. Part No.:
- CHVM1R5-12-1500N
- Brand:
- TDK-Lambda
Bulk discount available
Subtotal (1 unit)*
£204.98
(exc. VAT)
£245.98
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £204.98 |
| 5 - 9 | £198.83 |
| 10 - 24 | £192.68 |
| 25 - 49 | £186.53 |
| 50 + | £180.38 |
*price indicative
- RS Stock No.:
- 222-7209
- Mfr. Part No.:
- CHVM1R5-12-1500N
- Brand:
- TDK-Lambda
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK-Lambda | |
| Output Voltage 1 | 1500V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 12V | |
| Minimum Input Voltage | 12V | |
| Mount Type | Through Hole, Through Hole | |
| MTBF | 600000h | |
| Ripple and Noise | 25mV | |
| Output Current 1 | 1mA | |
| Maximum Output Power | 1.5W | |
| Weight | 50g | |
| Length | 16mm | |
| Standards/Approvals | RoHS | |
| Width | 44mm | |
| Series | CHVM | |
| Minimum Operating Temperature | -10°C | |
| Maximum Operating Temperature | 50°C | |
| Select all | ||
|---|---|---|
Brand TDK-Lambda | ||
Output Voltage 1 1500V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 12V | ||
Minimum Input Voltage 12V | ||
Mount Type Through Hole, Through Hole | ||
MTBF 600000h | ||
Ripple and Noise 25mV | ||
Output Current 1 1mA | ||
Maximum Output Power 1.5W | ||
Weight 50g | ||
Length 16mm | ||
Standards/Approvals RoHS | ||
Width 44mm | ||
Series CHVM | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature 50°C | ||
- COO (Country of Origin):
- JP
The TDK-Lambda CHVM series of non-isolated DC to DC converter with reduced radiated and conducted noise, less board area needed and simplified system compliance. It has 1 mA maximum current.
Low output ripple
Compact size
Safety certified
Five sided shielding
