TDK-Lambda CHVM DC-DC Converter, 0 → 180V dc/ 15mA Output, 10.8 → 13.2 V dc Input, 2.7W, Through Hole,
- RS Stock No.:
- 222-7224
- Mfr. Part No.:
- CHVM2R7-12-0180NW
- Brand:
- TDK-Lambda
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 222-7224
- Mfr. Part No.:
- CHVM2R7-12-0180NW
- Brand:
- TDK-Lambda
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TDK-Lambda | |
Output Voltage | 0 → 180V dc | |
Input Voltage Range | 10.8 → 13.2 V dc | |
Power Rating | 2.7W | |
Input Voltage Nominal | 12 V dc | |
Output Current | 15mA | |
Mounting Type | Through Hole | |
Isolated | No | |
Length | 12mm | |
Width | 80mm | |
Series | CHVM | |
Load Regulation | 0.015 | |
Medical Approved | Yes | |
Maximum Temperature | +50°C | |
Minimum Temperature | -10°C | |
Select all | ||
---|---|---|
Brand TDK-Lambda | ||
Output Voltage 0 → 180V dc | ||
Input Voltage Range 10.8 → 13.2 V dc | ||
Power Rating 2.7W | ||
Input Voltage Nominal 12 V dc | ||
Output Current 15mA | ||
Mounting Type Through Hole | ||
Isolated No | ||
Length 12mm | ||
Width 80mm | ||
Series CHVM | ||
Load Regulation 0.015 | ||
Medical Approved Yes | ||
Maximum Temperature +50°C | ||
Minimum Temperature -10°C | ||
- COO (Country of Origin):
- JP
The TDK-Lambda CHVM series of non-isolated DC to DC converter with reduced radiated and conducted noise, less board area needed and simplified system compliance. It has 15 mA maximum current.
Low output ripple
Compact size
Safety certified
Five sided shielding
Compact size
Safety certified
Five sided shielding
