Recom RFM DC/DC Converter, 5V dc/ 200 mA, 5.5V dc Input, 4.5V Input 1 W, Through Hole, 85 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 185-5527
- Mfr. Part No.:
- RFM-0505S
- Brand:
- Recom
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£1.68
(exc. VAT)
£2.02
(inc. VAT)
FREE delivery for orders over £60.00
Limited stock
- Plus 4 left, shipping from 21 September 2026
- Plus 2 left, shipping from 21 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £1.68 |
| 5 - 9 | £1.63 |
| 10 - 24 | £1.56 |
| 25 - 49 | £1.51 |
| 50 + | £1.46 |
*price indicative
- RS Stock No.:
- 185-5527
- Mfr. Part No.:
- RFM-0505S
- Brand:
- Recom
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Recom | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 5V dc | |
| Minimum Input Voltage | 4.5V | |
| Maximum Input Voltage | 5.5V dc | |
| Output Current 1 | 200mA | |
| Mount Type | Through Hole | |
| MTBF | 20100000h | |
| Number of Outputs | 1 | |
| Isolation Voltage | 1kV dc | |
| Number of Pins | 4 | |
| Maximum Output Power | 1W | |
| Package Type | SIP-4 | |
| Length | 11.5mm | |
| Depth | 10mm | |
| Width | 6mm | |
| Series | RFM | |
| Standards/Approvals | No | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 79% | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand Recom | ||
Product Type DC/DC Converter | ||
Output Voltage 1 5V dc | ||
Minimum Input Voltage 4.5V | ||
Maximum Input Voltage 5.5V dc | ||
Output Current 1 200mA | ||
Mount Type Through Hole | ||
MTBF 20100000h | ||
Number of Outputs 1 | ||
Isolation Voltage 1kV dc | ||
Number of Pins 4 | ||
Maximum Output Power 1W | ||
Package Type SIP-4 | ||
Length 11.5mm | ||
Depth 10mm | ||
Width 6mm | ||
Series RFM | ||
Standards/Approvals No | ||
Minimum Operating Temperature -40°C | ||
Efficiency 79% | ||
Maximum Operating Temperature 85°C | ||
- COO (Country of Origin):
- TW
RECOM DC-DC Converter, 1W Power Rating, 11.5 (L) x 6mm (W) - RFM Series - RFM-0505S
Use this DC-DC converter from RECOM to adjust the voltage supply to your industrial equipment. When it receives an input voltage supply between 4.5 and 5.5V DC, it transforms it to a safe output voltage level of 5V DC. As the unit also delivers electric isolation between the input and output supply, you can safely handle it without the risk of electric shock. This converter has an efficiency rating of 79%, so you can be sure of minimal energy loss during the conversion process.
Features & Benefits
• Compact dimensions of 11.5 (L) x 6 (W) x 10mm (D) to fit in small spaces
• Power rating of 1W for use in low-power devices
• Maximum output ripple and noise of 100mVp-p for minimal electrical disturbance
Applications
• Solar panels
• Consumer electronics
• Gaming systems
What's the operating temperature rating of this DC-DC converter?
This converter has a wide operating temperature range between -40°C and +85°C, which means it can withstand harsh industrial environments.
How do I mount this DC-DC converter?
The unit comes with through-holes in its body so you can quickly and easily mount it to a board without drilling new holes.
