Recom REC20 DC/DC Converter, 12V dc/ 835 mA, 36V dc Input, 18V Input 20 W, Through Hole, 100 °C Max Temp -40 °C Min
- RS Stock No.:
- 166-8799
- Mfr. Part No.:
- REC20-2412D
- Brand:
- Recom
Bulk discount available
Subtotal (1 tube of 18 units)*
£913.66
(exc. VAT)
£1,096.39
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 07 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £913.66 | £50.759 |
| 5 - 9 | £886.25 | £49.236 |
| 10 - 24 | £858.84 | £47.713 |
| 25 - 49 | £831.43 | £46.191 |
| 50 + | £804.02 | £44.668 |
*price indicative
- RS Stock No.:
- 166-8799
- Mfr. Part No.:
- REC20-2412D
- Brand:
- Recom
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Recom | |
| Output Voltage 1 | 12V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 36V dc | |
| Minimum Input Voltage | 18V | |
| Output Current 1 | 835mA | |
| Output Current 2 | 835mA | |
| Output Voltage 2 | -12V dc | |
| Mount Type | Through Hole | |
| Input Ratio | 2:1 | |
| MTBF | 607000h | |
| Number of Outputs | 2 | |
| Output Voltage Adjustment Range | ±10.8 V dc, ±13.2 V dc | |
| Ripple and Noise | 100mV Pk-Pk | |
| Number of Pins | 6 | |
| Isolation Voltage | 1.6kV dc | |
| Maximum Output Power | 20W | |
| Depth | 10.2mm | |
| Series | REC20 | |
| Length | 50.8mm | |
| Standards/Approvals | EN 60950-1 | |
| Weight | 27g | |
| Width | 25.4mm | |
| Maximum Operating Temperature | 100°C | |
| Efficiency | 89.5% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Recom | ||
Output Voltage 1 12V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 36V dc | ||
Minimum Input Voltage 18V | ||
Output Current 1 835mA | ||
Output Current 2 835mA | ||
Output Voltage 2 -12V dc | ||
Mount Type Through Hole | ||
Input Ratio 2:1 | ||
MTBF 607000h | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range ±10.8 V dc, ±13.2 V dc | ||
Ripple and Noise 100mV Pk-Pk | ||
Number of Pins 6 | ||
Isolation Voltage 1.6kV dc | ||
Maximum Output Power 20W | ||
Depth 10.2mm | ||
Series REC20 | ||
Length 50.8mm | ||
Standards/Approvals EN 60950-1 | ||
Weight 27g | ||
Width 25.4mm | ||
Maximum Operating Temperature 100°C | ||
Efficiency 89.5% | ||
Minimum Operating Temperature -40°C | ||
Recom REC20 Series Isolated DC-DC Converter
Recom REC20 series have been designed for use within higher power industrial applications. Boasting both single and dual regulated output functionality within a compact 2" x 1" package.
The REC20 series also comes equipped with remote on/off control as standard to provide flexibility within applications. Another benefit of the REC20 series is track loss voltage compensation within the higher current output variants of the range.
Features and Benefits
•Highly efficient range of DC-DC converters, boasting up to 90.5% efficiency.
•External ON / OFF control for application flexibility.
•Isolated to 1.6 k V dc.
•Continuous short circuit protection.
•6-side shielding.
Recom Isolated DC/DC Converter
Standards
IEC/EN60950-1, UL60950-1, CSA C22.2 No. 60950 & EN55022 Certified.
