Name: TRACOPOWER THM 15 DC-DC Converter, 15V dc/ 1A Output, 18 → 36 V dc Input, 15W, Through Hole, +85°C Max Temp
Brand: TRACOPOWER
SKU: 165-1324
Price: 58.32 GBP
Availability: Discontinued

TRACOPOWER THM 15 Series DC-DC Converter, 15W Power Rating, 1A Output Current - THM 15-2413

This isolated DC-DC converter is designed for medical applications, providing a reliable 15W output. Encased in a compact package measuring 1.6 x 1 in, it operates within an input voltage range of 18V to 36V DC, delivering a precise 15V output with a current rating of 1A. The converter also ensures high efficiency, achieving up to 90% conversion.

Features & Benefits

• Offers reinforced isolation rated at 5000VAC for safety
• Low leakage current of less than 2.5 00B5 (μ) A enhances reliability
• Operating temperature ranges from -40°C to +85°C for broad use
• Adjustment of output voltage from –10% to +20% for flexibility
• High efficiency reduces energy consumption and heat generation
• Compliance with medical standards ensures suitability for criticality

Applications

• Ideal for medical equipment requiring strict safety standards
• Suitable for control and measurement systems in automation
• Used in transportation electronics to manage power effectively
• Compatible with IGBT drivers in high-performance

What isolation features does this device provide to ensure user safety?

It features a reinforced isolation system rated for 5000VAC, ensuring safe operation, particularly in medical applications where safety is paramount.

How does the operating temperature range affect the converter's functionality?

The device can function without issues in temperatures ranging from –40°C to +85°C, making it suitable for diverse environments, including extreme conditions.

What is the significance of the low leakage current specification?

A low leakage current of less than 2.5 00B5 (μ) A indicates minimal energy loss and enhances safety, especially in medical applications where patient protection is critical.

Can the output voltage be adjusted?

Yes, the output voltage is adjustable from –10% to +20%, allowing flexibility in various applications and accommodating different system requirements.

What advantages does high efficiency bring to my application?

High efficiency, reaching up to 90%, results in reduced power consumption and lower heat generation, contributing to overall system reliability and longevity.

Select all	Attribute	Value
	Brand	TRACOPOWER
	Output Voltage	15V dc
	Input Voltage Range	18 → 36 V dc
	Power Rating	15W
	Input Voltage Nominal	24 V dc
	Output Current	1A
	Mounting Type	Through Hole
	Isolated	Yes
	Number of Outputs	1
	Output Voltage Adjustment Range	-10 → +20%
	Package	1.6 x 1 in
	Isolation Voltage	5kV ac
	Depth	10.2mm
	Length	40.6mm
	Width	25.4mm
	Series	THM 15
	Load Regulation	0.002
	Medical Approved	Yes
	Standards Met	ANSI/AAMI ES 60601-1, CB Scheme IEC 60601-1, cULus Recognised, EMC, EN 55011, EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, ES60601-1, IEC 60601-1-2, IEC/EN 60601-1, MIL-STD-810F
	Maximum Temperature	+85°C
	Minimum Temperature	-40°C

	Select all
	Brand TRACOPOWER
	Output Voltage 15V dc
	Input Voltage Range 18 → 36 V dc
	Power Rating 15W
	Input Voltage Nominal 24 V dc
	Output Current 1A
	Mounting Type Through Hole
	Isolated Yes
	Number of Outputs 1
	Output Voltage Adjustment Range -10 → +20%
	Package 1.6 x 1 in
	Isolation Voltage 5kV ac
	Depth 10.2mm
	Length 40.6mm
	Width 25.4mm
	Series THM 15
	Load Regulation 0.002
	Medical Approved Yes
	Standards Met ANSI/AAMI ES 60601-1, CB Scheme IEC 60601-1, cULus Recognised, EMC, EN 55011, EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, ES60601-1, IEC 60601-1-2, IEC/EN 60601-1, MIL-STD-810F
	Maximum Temperature +85°C
	Minimum Temperature -40°C
