TRACOPOWER TIM 2 Isolated DC-DC Converter, 24V dc/ 83mA Output, 9 → 18 V dc Input, 2W, Through Hole, +105°C Max
- RS Stock No.:
- 152-7036
- Mfr. Part No.:
- TIM 2-1215
- Brand:
- TRACOPOWER
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 152-7036
- Mfr. Part No.:
- TIM 2-1215
- Brand:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 24V dc | |
| Input Voltage Range | 9 → 18 V dc | |
| Power Rating | 2W | |
| Input Voltage Nominal | 12 V dc | |
| Output Current | 83mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Package | DIP 16 | |
| Isolation Voltage | 5kV ac | |
| Depth | 10.2mm | |
| Width | 14.4mm | |
| Length | 24.3mm | |
| Series | TIM 2 | |
| Load Regulation | 1% | |
| Maximum Temperature | +105°C | |
| Standards Met | AAMI/ANSI ES 60601-1, EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC/EN 60601-1, MIL-STD-810F | |
| Minimum Temperature | -40°C | |
| Medical Approved | Yes | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 24V dc | ||
Input Voltage Range 9 → 18 V dc | ||
Power Rating 2W | ||
Input Voltage Nominal 12 V dc | ||
Output Current 83mA | ||
Mounting Type Through Hole | ||
Number of Outputs 1 | ||
Package DIP 16 | ||
Isolation Voltage 5kV ac | ||
Depth 10.2mm | ||
Width 14.4mm | ||
Length 24.3mm | ||
Series TIM 2 | ||
Load Regulation 1% | ||
Maximum Temperature +105°C | ||
Standards Met AAMI/ANSI ES 60601-1, EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC/EN 60601-1, MIL-STD-810F | ||
Minimum Temperature -40°C | ||
Medical Approved Yes | ||
