TRACOPOWER TIM 2 DC-DC Converter, 5V dc/ 400mA Output, 18 → 36 V dc Input, 2W, Surface Mount, +105°C Max Temp
- RS Stock No.:
- 152-6920
- Mfr. Part No.:
- TIM 2-2411SM
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£26.74
(exc. VAT)
£32.09
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 10 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £26.74 |
5 - 9 | £25.94 |
10 - 24 | £25.13 |
25 - 49 | £24.06 |
50 + | £22.99 |
*price indicative
- RS Stock No.:
- 152-6920
- Mfr. Part No.:
- TIM 2-2411SM
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TRACOPOWER | |
Output Voltage | 5V dc | |
Input Voltage Range | 18 → 36 V dc | |
Power Rating | 2W | |
Input Voltage Nominal | 24 V dc | |
Output Current | 400mA | |
Mounting Type | Surface Mount | |
Isolated | Yes | |
Number of Outputs | 1 | |
Package | SMD 16 | |
Isolation Voltage | 5kV ac | |
Width | 14.4mm | |
Depth | 10.5mm | |
Length | 24.3mm | |
Series | TIM 2 | |
Load Regulation | 0.01 | |
Medical Approved | Yes | |
Minimum Temperature | -40°C | |
Maximum Temperature | +105°C | |
Standards Met | AAMI/ANSI ES 60601-1, EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC/EN 60601-1, MIL-STD-810F | |
Select all | ||
---|---|---|
Brand TRACOPOWER | ||
Output Voltage 5V dc | ||
Input Voltage Range 18 → 36 V dc | ||
Power Rating 2W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 400mA | ||
Mounting Type Surface Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package SMD 16 | ||
Isolation Voltage 5kV ac | ||
Width 14.4mm | ||
Depth 10.5mm | ||
Length 24.3mm | ||
Series TIM 2 | ||
Load Regulation 0.01 | ||
Medical Approved Yes | ||
Minimum Temperature -40°C | ||
Maximum Temperature +105°C | ||
Standards Met AAMI/ANSI ES 60601-1, EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC/EN 60601-1, MIL-STD-810F | ||
- COO (Country of Origin):
- TW
TRACOPOWER TIM 2 Series DC-DC Converter, 5V Voltage Rating, 400mA Output Current - TIM 2-2411SM
This isolated DC-DC converter delivers a 5V output with a power rating of 2W, designed for stable performance in demanding medical applications. The compact SMD16 package measures 14.4mm x 24.3mm x 10.5mm, making it suitable for space-constrained environments while ensuring effective heat dissipation and operational efficiency.
Features & Benefits
• High efficiency of 79% enhances overall system performance
• Input voltage range of 18 to 36V ensures versatility
• Reinforced isolation rated at 5000VAC for enhanced safety
• Low leakage current under 2 00B5 (μ) A supports patient safety
• Operating temperature range from -40°C to +95°C for robust
• Complies with medical safety standards for reliability in critical environments
• Input voltage range of 18 to 36V ensures versatility
• Reinforced isolation rated at 5000VAC for enhanced safety
• Low leakage current under 2 00B5 (μ) A supports patient safety
• Operating temperature range from -40°C to +95°C for robust
• Complies with medical safety standards for reliability in critical environments
Applications
• Ideal for portable electronic health devices requiring compact solutions
• Employed in automation systems needing reliable 5V power
• Utilised for peripheral devices in sensitive electronic setups
• Employed in automation systems needing reliable 5V power
• Utilised for peripheral devices in sensitive electronic setups
What input voltage range can be accommodated, and what does that mean for usage?
The input voltage range is 18 to 36V, allowing flexibility in various applications from industrial power supplies to medical devices, ensuring compatibility with diverse systems while maintaining consistent performance.
How does this converter ensure safety in medical settings?
It features reinforced isolation rated at 5000VAC, which provides a secure barrier between input and output, greatly reducing the risk of electrical shocks, making it suitable for direct patient contact.
What thermal management features are incorporated for high-temperature applications?
It operates efficiently within a wide temperature range of -40°C to +95°C, ensuring reliable performance even in extreme conditions, and includes natural convection cooling to maintain optimal operating temperatures.
