TRACOPOWER TDN 3WISM DC-DC Converter, 24V dc/ 125mA Output, 9 → 36 V dc Input, 3W, Surface Mount, +70°C Max Temp
- RS Stock No.:
- 143-6467
- Mfr. Part No.:
- TDN 3-2415WISM
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£22.09
(exc. VAT)
£26.51
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 11 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £22.09 |
| 5 - 9 | £21.43 |
| 10 - 24 | £20.78 |
| 25 - 49 | £19.89 |
| 50 + | £19.00 |
*price indicative
- RS Stock No.:
- 143-6467
- Mfr. Part No.:
- TDN 3-2415WISM
- Brand:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 24V dc | |
| Input Voltage Range | 9 → 36 V dc | |
| Power Rating | 3W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 125mA | |
| Mounting Type | Surface Mount | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Package | SMD | |
| Isolation Voltage | 1.6kV dc | |
| Length | 13.2mm | |
| Depth | 9.9mm | |
| Width | 9.1mm | |
| Series | TDN 3WISM | |
| Load Regulation | 0.01 | |
| Standards Met | EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, MIL-STD-810F | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +70°C | |
| Efficiency | 82% | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 24V dc | ||
Input Voltage Range 9 → 36 V dc | ||
Power Rating 3W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 125mA | ||
Mounting Type Surface Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package SMD | ||
Isolation Voltage 1.6kV dc | ||
Length 13.2mm | ||
Depth 9.9mm | ||
Width 9.1mm | ||
Series TDN 3WISM | ||
Load Regulation 0.01 | ||
Standards Met EN 55022, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, MIL-STD-810F | ||
Minimum Temperature -40°C | ||
Maximum Temperature +70°C | ||
Efficiency 82% | ||
