Cosel MGW DC/DC Converter, 30V dc, -30 V dc/ 500 mA, 24V dc Input, 18V Input 15 W, PCB, 85 °C Max Temp -40 °C Min Temp,

View all DC-DC Converters

Subtotal (1 unit)*

£17.61

(exc. VAT)

£21.13

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 6 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£17.61

*price indicative

RS Stock No.:
130-9714
Mfr. Part No.:
MGW152415-R
Brand:
Cosel
Find similar products by selecting one or more attributes.
Select all

Brand

Cosel

Product Type

DC/DC Converter

Output Voltage 1

30, -30V dc

Maximum Input Voltage

24V dc

Minimum Input Voltage

18V

Output Current 1

500mA

Output Current 2

0.5A

Mount Type

PCB

Number of Outputs

2

Ripple and Noise

150mV Pk-Pk

Output Voltage Adjustment Range

14.602 to 15.505 V

Isolation Voltage

1.5kV dc

Number of Pins

6

Package Type

DIP

Maximum Output Power

15W

Depth

9.9mm

Width

9.9mm

Series

MGW

Standards/Approvals

CE, cUL, cULus, EN 60950-1, TUV, UL 60950-1

Weight

20g

Length

25.4mm

Efficiency

89%

Maximum Operating Temperature

85°C

Minimum Operating Temperature

-40°C

MGW Series, On/Off Remote Function


The MGW Series of Cosel DC-DC converters provide a wide input range with high efficiency. The MGW Series from Cosel offer the best quality in DC-DC converters with high reliability and On/Off Remote Function.

Features and Benefits


• Industry Standard SIP6 (MG1R5 / MG3), SIP8 (MG6 / MG10), 1"X1" (MG15), 1"X2" (MG30)

• High reliability: no built-in aluminium and tantalum electrolytic capacitor

• 6 sided shield (MG15 / MG30)

• I/O isolation voltage DC1,500 V (1 min)

• Built-in overvoltage protection circuits (MG30)

• Built-in remote On/Off Function

• Built-in overcurrent protection circuits (recovers automatically)

• 10 Year Warranty

Cosel Isolated DC-DC Converters
