Cosel MGW DC/DC Converter, 24V dc, -24 V dc/ 650 mA, 24V dc Input, 18V Input 15.6 W, PCB, 85 °C Max Temp -40 °C Min
- RS Stock No.:
- 130-9713
- Mfr. Part No.:
- MGW152412-R
- Brand:
- Cosel
Bulk discount available
Subtotal (1 unit)*
£37.00
(exc. VAT)
£44.40
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 10 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £37.00 |
| 5 - 9 | £35.89 |
| 10 - 24 | £35.15 |
| 25 - 49 | £34.41 |
| 50 + | £33.67 |
*price indicative
- RS Stock No.:
- 130-9713
- Mfr. Part No.:
- MGW152412-R
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Output Voltage 1 | 24, -24V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 24V dc | |
| Minimum Input Voltage | 18V | |
| Output Current 1 | 650mA | |
| Output Current 2 | 0.65A | |
| Mount Type | PCB | |
| Number of Outputs | 2 | |
| Output Voltage Adjustment Range | 11.765 to 12.492 V | |
| Ripple and Noise | 150mV Pk-Pk | |
| Number of Pins | 6 | |
| Isolation Voltage | 500V dc | |
| Package Type | DIP | |
| Maximum Output Power | 15.6W | |
| Length | 25.4mm | |
| Series | MGW | |
| Width | 9.9mm | |
| Standards/Approvals | cUL, CE, UL 60950-1, TUV, EN 60950-1, cULus | |
| Weight | 20g | |
| Depth | 9.9mm | |
| Efficiency | 88% | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Output Voltage 1 24, -24V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 24V dc | ||
Minimum Input Voltage 18V | ||
Output Current 1 650mA | ||
Output Current 2 0.65A | ||
Mount Type PCB | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range 11.765 to 12.492 V | ||
Ripple and Noise 150mV Pk-Pk | ||
Number of Pins 6 | ||
Isolation Voltage 500V dc | ||
Package Type DIP | ||
Maximum Output Power 15.6W | ||
Length 25.4mm | ||
Series MGW | ||
Width 9.9mm | ||
Standards/Approvals cUL, CE, UL 60950-1, TUV, EN 60950-1, cULus | ||
Weight 20g | ||
Depth 9.9mm | ||
Efficiency 88% | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- JP
MGW Series, On/Off Remote Function
The MGW Series of Cosel DC-DC converters provide a wide input range with high efficiency. The MGW Series from Cosel offer the best quality in DC-DC converters with high reliability and On/Off Remote Function.
Features and Benefits
• Industry Standard SIP6 (MG1R5 / MG3), SIP8 (MG6 / MG10), 1"X1" (MG15), 1"X2" (MG30)
• High reliability: no built-in aluminium and tantalum electrolytic capacitor
• 6 sided shield (MG15 / MG30)
• I/O isolation voltage DC1,500 V (1 min)
• Built-in overvoltage protection circuits (MG30)
• Built-in remote On/Off Function
• Built-in overcurrent protection circuits (recovers automatically)
• 10 Year Warranty
